Bd-10 – Barranca Diamond BD10 Power Feed Trim Saw User Manual
Page 2
2
Thank you for selecting the Barranca Diamond BD10 Trim Saw. We are certain that you will be pleased with
your purchase. Barranca Diamond takes pride in producing top quality products for hobbyists and commercial
lapidary users throughout the world.
This owner’s manual contains information necessary to operate and maintain your BD10 Trim Saw safely and
correctly. Operated correctly, your BD10 Trim Saw should provide you with years of service. Please take the
time to familiarize yourself with the BD10 Trim Saw by reading and reviewing this manual.
If you should have questions concerning your BD10 Trim Saw, please call Barranca Diamond at:
(310) 523-5867 or Toll Free: (800) 365-0085.
SAFETY
Safety Precautions
3
California Proposition 65 Message
6
Electrical Requirements
7
PRODUCT SPECIFICATIONS
9
Oil/Coolant
10
SETUP
Contents
11
Unpacking and Assembly
11
Transport
11
OPERATION AND ADJUSTMENT
Pre-start Inspection
12
Start Up
13-14
Slab Sawing Mode
15
Trim Sawing Mode
16
MAINTENANCE
Cutting Lubricant Replacement
17
V-Belt
18
Power Feed System and Vise
19
Blade Arbor Assembly and Pulleys
19-20
Main Motor
20
Diamond Blade
21
Blade Installation and Removal
22
EXPLODED VIEW AND PARTS LIST
Exploded View & Parts List
24-29
WARRANTY, RETURN, & CUSTOMER SERVICE
Warranty
30-31
Return & Customer Service
32
TABLE OF CONTENTS
BD-10
