With the hip end tent complete, adjust the guy webs for even tightness. Note: guy webs are
staked out from the baseplates by a distance equal to the height of the uprights so that the
web angle is 45 degrees to the ground (fig. 43).
Walls are optional, but in the wind, the tent is safest when the walls are either all closed or
all open.
The Navi-Trac LT can also be configured in the following ways:
1. As a Guyed Unit With (2) Gabled Ends
2. As a Guyed Unit With (1) Gabled End and (1) Hip End
3. As a Guyed Unit With (2) Hex Ends
4. As a Guyed Unit With (1) Hex End and (1) Gabled or Hip End
3. As a Clearspan Unit with no Guys
For Proper Configuration of these frame variations, see Appendices 1 and 2.
