AirLive WIAS-3200N - Manual (Page 62)

7. Access Network without Authentication
59 AirLive WIAS-3200N User’s Manual
7 7 Access Network without
Authentication
7.1 DMZ
Configure DMZ, go to: Network >> Network Address Translation >> DMZ
(Demilitarized Zone).
There are 20 sets of static Internal IP Address and External IP Address available. Enter
Internal and External IP Address as a set. After the setup, accessing the External IP
address listed in DMZ will be mapped to accessing the corresponding Internal IP Address.
These settings will become effective immediately after clicking the Apply button. The
External IP Address of the Automatic WAN IP Assignment is the IP address of External
Interface (WAN) that will change dynamically if WAN Interface is Dynamic. When
Automatic WAN IP Assignments is enabled, the entered Internal IP Address of Automatic
WAN IP Assignment will be bound with WAN interface.
