2. System Overview and Getting Started
AirLive WIAS-3200N User’s Manual
10
2.5 Installation Steps
Please follow the steps below to install WIAS-3200N:
Please follow the steps mentioned below to install the hardware of WIAS-3200N:
1. Place the WIAS-3200N at a best location.
The best location for WIAS-3200N is usually at the center of your wireless network.
2. Connect WIAS-3200N to your outbound network device.
Connect one end of the Ethernet cable to the WAN port of WIAS-3200N on the front
panel. Depending on the type of internet service provided by your ISP, connect the
other end of the cable to the ATU-Router of an ADSL, a cable modem, a switch or a
hub. The WAN LED indicator should be ON to indicate a proper connection.
3. Connect WIAS-3200N to your network device.
Connect one end of the Ethernet cable to the LAN1 port of WIAS-3200N on the front
panel. Connect the other end of the cable to a PC for configuring the system. The LAN1
LED indicator should be ON to indicate a proper connection.
Note:
WIAS-3200N has two virtual zones Private and Public which are mapped to
LAN1(192.168.1.254) and LAN2(192.168.11.254) respectively.
4. There are two ways to supply power over to WIAS-3200N.
(a) Connect the DC power adapter to the WIAS-3200N power socket on the front
panel.
(b) WIAS-3200N is capable of transmitting DC current via its WAN PoE port. Connect
an IEEE 802.3af-compliant PSE device, e.g. a PoE-switch, to the WAN port of
WIAS-3200N with the Ethernet cable.
5. Now, the hardware installation is completed.
6. Caution:
Please only use the power adapter supplied with the WIAS-3200N package. Using a
different power adapter may damage this system.
7. Caution:
To double verify the wired connection between WIAS-3200N and your
switch/router/hub, please check the LED status indication of these network devices.
