WAN Interface
Using the WAN Interface, the Administrator sets up the WAN network. These IP Addresses
are real public IP Addresses, and are routable on the Internet.
For PPPoE (ADSL User): This option is for PPPoE users who are required to enter a
username and password in order to connect, such as ADSL users.
Current Status: Displays the current line status of the PPPoE connection.
IP Address: Displays the IP Address of the PPPoE connection
Username: Enter the PPPoE username provided by the ISP.
Password: Enter the PPPoE password provided by the ISP.
IP Address provided by ISP:
Dynamic: Select this if the IP address is automatically assigned by the ISP.
Fixed: Select this if you were given a static IP address. Enter the IP address that is
given to you by your ISP.
Max. Upstream/Downstream Bandwidth: The bandwidth provided by ISP.
Service-On-Demand:
Auto Disconnect: The PPPoE connection will automatically disconnect after a length
of idle time (no activities). Enter in the amount of idle minutes before disconnection.
Enter ‘0’ if you do not want the PPPoE connection to disconnect at all.
Ping: Select this to allow the WAN network to ping the IP Address of the Bandwidth
Manager. This will allow people from the Internet to be able to ping the Bandwidth
Manager. If set to enable, the device will respond to echo request packets from the
WAN network.
WebUI: Select this to allow the device WEBUI to be accessed from the WAN network.
This will allow the WebUI to be configured from a user on the Internet. Keep in mind
that the device always requires a username and password to enter the WebUI.
