AirLive FE-200CU - Manual (Page 56)

5. Appendix
AirLive FE-200CU Manual 50
Audio Streaming One-way or Two-way
Microphone Built-in Microphone
Audio Output Built-in Speaker
Network
Supported Protocols
HTTP, TCP/IP, IPv4, UDP, SMTP, FTP, DHCP, DDNS, NTP,
DNS, ARP, RTSP, RTP, Samba Clinet, UPnP
Security Password protection, user access log
Ethernet 10/100M auto negotiation
System Integration
Application
Programming Interface
Open API for software integration
SDK
Alarm Triggers Intelligent video motion detection and external input
Motion Detection
Up to 10 motion detection areas with included or excluded
options
Alarm Events
File upload via FTP ,SD Card or email
Notification via email, HTTP,
External output activation
General
RAM 128MB
ROM 2GB
Power Supply 12V DC external power adapter
PoE IEEE 802.3af
Power Consumption 5W
IP Level None
Vandal proof None
Connectors
1 x RJ-45 10BaseT/100BaseTX
1 x DC power jack
1 x Terminal Connector
1 x Audio Line out and 1 x Audio Line in
1x Micro SD Slot
1 x DI and 1 x DO
Indication LED Green and orange LEDs
Mechanical IR-cut Yes
Operating Temperature 0°C to 50°C (32°F to 122°F)
Operating Humidity 20% ~ 80% (non-condensing)
Dimension HxWxD:83 x 83 x 60mm
Viewing System
OS Windows® XP, Vista, 7
Browser IE 6.0 or later, Firefox 2.0 or later, Safari
Cell Phone With 3GPP player
Video Player VLC, Quick Time, Real Player, Core Player
