5. Appendix
AirLive FE-200CU Manual 49
Actual results generated by the device may be varying.
Resolution
Average range of
data sizes for
JPEG mode
Average bit rate for
MPEG4 mode
Average bit rate for
H.264 mode
160 x 120
(QQVGA)
3 ~ 6k byte per
frame
64kbps~256kbps
@ 30fps
32kbps~192kbps
@ 30fps
320 x 240
(QVGA)
8 ~ 20k byte per
frame
256kbps~768kbps
@ 30fps
192kbps~512kbps
@ 30fps
640 x 480
(VGA)
20 ~ 50K byte per
frame
512kbps~2048kbps
@ 30fps
384kbps~1536kbps
@ 30fps
1280x1024
(SXGA)
100 ~ 200k byte
per frame
NA 512kbps~3076kbps
@ 15fps
Note: Audio streaming also takes bandwidth around 32kbps. Some xDSL/Cable modem
upload speeds could not even reach up to 128 kbps. Thus, you may not be able to
receive good quality video while also streaming audio on a 128 kbps or lower connection.
Even though the upload speed is more than 128kbps, for optimal video performance,
disabling audio streaming will get better video performance.
Appendix E: Specifications
Camera
Model Name FE-200CU
Image Device 2 Mega-pixel image sensor
Effective Pixels 1600 x 1200 pixels
Lens
Fish-Eye Lens
Focal Length: F2.0 /f = 1.25mm
FOV=185°(D/H/V)
IP Module
Video
Video Encoder H.264, Motion JPEG
Frame Rate 4:3 Res. @ 15 FPS; 16:9 Res. @ 30 FPS
Image Setting
Brightness, Sharpness, Saturation, Exposure, White balance
control
Streaming HTTP, TCP/IP, IPv4, UDP, SMTP, FTP, DHCP, DDNS, NTP,
DNS, ARP, RTSP, RTP, Samba Clinet, UPnP
Audio
Audio Encoder RTSP: G.711 64kbps
