3.5 Managed Switch
Network segments can be set up without any additional hardware by using the managed switch integrated into
the firewall. It is possible to connect multiple systems or terminals up to one Firewall.
Each port can be switched off individually to prevent unauthorized data traffic monitoring.
3.6 Service
Service access via a secure service port.
Connecting the Firewall to an analogue, ISDN or GPRS modem for dial‐in access provides for affordable remote
maintenance, even without an Internet connection.
3.7 Equipment Versions
The device is available in 4 configuration versions:
Ausstattungsvariante IF1100 IF1110 IF1200 IF1210
LAN‐in RJ45 RJ45 LWL LWL
LAN‐out RJ45 RJ45 RJ45 RJ45
NVRAM ‐ X ‐ X
RJ45 (Registered Jack 45 = standardized jack) provided per an Ethernet standard as frequently implemented in
telecom applications. The transmission method is equivalent to 10/100Mbits half and full DUPLEX 100 BASE‐TX.
LWL (fibre optic connection) are flexible optic media for controlled conduction of light. Contrarily to the Ethernet
standard, the fibre optic connection technology is insensitive to voltage interference.
The plugs required for implementation are equivalent to the MTRJ Standard Multimode with a 100Base‐FX 100
Mbit⁄s Ethernet transmission method via fibre op cs.
NVRAM (non‐volatile RAM = non‐volatile Random Access Memory) is an electronic memory storage technology
whereby data is stored even without maintenance of power supply.
Note:
The LAN‐in interface can be equipped with an RJ45 or with an LWL fibre optic
connection, as the case may be.
3.8 Scope of Delivery
Please check supply package contents for integrity and completeness:
Scope of Delivery IF1000 series
 1 x Industrial Firewall
 2 x 2 pole Plug
 1 x 4 pole.Plug
 Ethernetcable 1m
 Quick Guide Inbetriebnahme / Quick Guide Montage
 GNU General Public License
 Service‐CD
