5 Systemfeatures
5.1 Frontpanel Operation Keys
The device is provided with operation keys for navigation and unit configuration via the LCD menus. Said LCD
menus are easily accessed via simple operation of the ESC or the ENTER keys. You will find a description of the
single menu items in the following LC display section.
The front panel operation keys are provided with the following functions:
Symbol Navigation function Configuration function
Press to exit the current menu
level.
(ESC))
If the input mode is activated,
the variation can be
overruled/abandoned by
pressing ESC.
Press to access a menu level or to
confirm a change entry.
(ENTER)
To enter or to change data, the
input mode must first be
activated by pressing ENTER.
This will have only one digit
flashing.
To adopt the change entries, the
input mode must first be
deactivated by pressing ENTER.
This will highlight the whole
line.
For selection amongst a number
of options, selection is activated
via this key. selection of either
German or English from the
available language options).
Menu navigation direction arrow
(UP)
For selection amongst a number
of options, the UP key will
access and highlight the
selection item in ascending/up
order (e.g. selection of either
German or English from the
available language options).
Upon entry or change of various
data, the highlighted digit can
be accessed and changed in
ascending/up direction.
The succession of the characters
is provided in the ASCII code.
However, a space character is
assigned for simplification of
first‐time operation of the
DOWN navigation direction
option. If the key is pressed a
second time, the system
proceeds with ASCII character
strings.
