2N BRI Lite/Enterprise v1.1 - Manual (Page 70)

70
63 Service or option unavailable 503 Service unavailable
65 Bearer cap, not implemented 501 Not implemented
79 Service or option not
implemented
501 Not implemented
87 User not member of CVG 603 Decline
88 Incompatible destination 400 Bad request
98 Invalid message 400 Bad request
102 Recover on timer expiry 408 Request timeout
XXX Other received CAU from netw. 500 Internal server error
Others
 Text of SMS at no answer – edit the text of the SMS to be sent to the calling
party in case of no answer (if the function is active). The %N string will insert
the CLIP received from VoIP in the SMS text.
 Text of SMS for all calls – complete this parameter to make the GSM gateway
send SMS to every called party regardless of whether or not the call was
successfully connected. The %N string will insert the CLIP received from VoIP
in the SMS text.
 Save received SMS to – select the storage for received SMS messages.
 SIM card identification – set the SIM Id (IMSI/SCID) to be entered in the
CDR.
 Disable CLIP from GSM/UMTS to VoIP – enable/disable resending of the CLIP
from GSM to VoIP.
 Reject call with CHLD – enable rejection of incoming calls from GSM/UMTS via
AT+CHLD (subscriber busy) instead of standard ATH.
GSM group assignment
Here you can assign the GSM/UMTS modules to groups. You can assign incoming
and outgoing calls separately using the parameters below.
GSM outgoing groups
2N BRI gateway allows you to work with two groups of outgoing calls. You can set
different values (call setup, called minutes and sent SMS per period, etc.) for each
of them.
General settings
 Delay for CONNECT [s] – set the delay between receiving a GSM call and
sending the CONNECT message.
 Minimum ring duration to send SMS at no answer [s] – set the minimum
ringing timeout for sending the SMS at no answer.
