List of emergency numbers
The window displays a list of emergency numbers, which are normally routed to
the BRI interface. If the BRI line is disconnected, the emergency numbers are
dialled automatically via any GSM/UMTS module according to the following rules:
- Search of a logged-in GSM/UMTS module (regardless of free minutes);
- Search of a blocked or network searching GSM/UMTS module.
The table includes an exact format of the number to be called (112,911, etc.). The
„x’ placeholder stands for any digit in the number to be called. The „_’ placeholder
means the rest of the number. For example:
Format Allowed numbers
123 123 only
14x0 1400,1410,1420,…1490
999_ All numbers starting with 999
VoIP parameters
VoIP functions
 Day of deleting statistics on VoIP (every month) – set the day for automatic
deletion of call statistics via the VoIP interface. None = statistics will not be
deleted automatically.
SIP protocol settings
 Use CLIP from INVITE field – define that CLIP from the „Contact‟ or „From‟
field shall be used for call routing to GSM/UMTS.
 Send 180 ringing instead of 183 session progress.
 Send 200 OK instead of 180/183.
 Send 200 OK and BYE when rejected from GSM.
 Send 200 OK on REGISTER request – virtual registration of device in 2N BRI
gateway (for registration requiring equipment).
 Replace CLIP from GSM with Caller ID.
 Deny DTMF according to RFC2833.
 Forward DTMF for ME.
SIP registration
 Registration expires [s] – set the expiration time for the 2N BRI gateway
registration data with SIP proxy.
 Reattempt registration [s] – set the time interval after which the request shall
be resent.
 Registration domain (realm).
 Caller ID.
 Username - registration data with SIP proxy.
 Password – registration data with SIP proxy.
Voice parameters
