2 relay outputs
2 digital inputs
WIEGAND interface
Signalling outputs (LED / buzzer)
Specifications:
Card reader
Compatible with EM4100 / EM4102 / HID Prox RFID cards
®
Working frequency: 125 KHz
Minimum reading distance: 10 mm above
cover 2N
®
Helios IP Vario
Relay outputs
Switching contact
30V / 1A AC / DC
Logical inputs
Active mode – requires external voltage (JP2 jumper OFF)
U = min +2.5 V
IN-ON
U = max +1.5 V
IN-OFF
U = +48 V
IN max
I (U +48 V) = max 1 mA
IN IN
Passive mode – requires external contact only (JP2 jumper ON)
U = approx. 8.3 V
OUT
I = approx. 0.5 mA
LOOP
Signalling outputs
5 V or 12V DC voltage
270 ohm current limiter
WIEGAND interface
Input / Output (as programmed)
