2N StarGate/BlueTower v5.5 User Manual

Page 83

Maximum number of called minutes – define the maximum count of minutes
to be called within a month via the selected SIM card.

Count of SMS messages – define the maximum count of SMS messages to be
sent within a month via the selected SIM card.
Day of restoring call limit and delete statistics – select a day in a month on
which the Max count of called minutes and Count of SMS messages statistics
shall be deleted.
First count – set the length of the first pulse after which the pulse counting
change starts as defined in the Next count parameter.
Next count – set the length of one pulse in seconds after the time defined in the
First count parameter elapses.

Day limit of called minutes – set the maximum count of minutes to be called
within a day via the selected SIM card.

– set the interval to send AOC messages

AOC sending interval

Time Limits

There are two SIM use time limits in a GSM group.

Call tariffs – use this function to assign up to four independent free minute counters
to a group of GSM modules (SIM cards), e.g.:

Tariff 1 = free minutes for calls to own GSM/UMTS network.
Tariff 2 = free minutes for calls to other GSM/UMTS networks.
Tariff 3 = free minutes for calls to fixed network.
Tariff 4 = free minutes for calls within a closed user group (VPN).

Complete the LCR table (assign prefixes to tariffs) properly to make full use of this
function. If routing to a tariff is not used, the global free minutes function will be used
in the LCR table.

Free minutes – set the free minutes for the tariff offered by the provider.
Transferred minutes – set the maximum count of free minutes to be
transferred to the next period.

– set the interval to send AOC messages.

AOC sending interval
Day of restoring free minutes – set a day on which the free minute counters
will be reset automatically. Select every 24 hours, a day in a month, or a day in a
week.
Week of restoring free minutes in month – set a week in which the free
minute counters will be reset automatically. Set the week number only if the
restoration takes place

in a month, e.g., or keep

for

every other Friday

Every

the other cases.

Caution

The

and

services

Temporary CLIP enable

Temporary CLIR enable

must be supported by the GSM/UMTS provider’s network. Otherwise, the
call may be rejected by GSM/UMTS!

Note

Set the two parameters above (

) properly to

First count, Next count

count free minutes on SIM cards correctly. These parameters are used for
limiting outgoing calls depending on free minutes. The CDRs contain real
data.
