6
WARNING: Wear safety glasses during
operation. Wear proper clothing to
protect feet, legs, and other exposed body
parts.
Do not operate without all guards in place or in
the vicinity of bystanders or personal property.
The intended use of the EZ TrimMower is trimming, mowing,
and edging. It can be used as a mower or trimmer and edger after
mowing with a lawn mower.
WARNING: Inspect and clean engine
before each use. Debris accumulation
around the muffler can cause a fire.
To begin trimming, with the engine running, place the trimmer
head on the ground and begin walking slowly. The wheels
should remain grounded at all times to prevent undue pressure on
the trimmer head. The cutting radius is dependent on the amount
of cutting string used and type of application. For difficult
conditions and edging, using less than the full cutting radius is
recommended.
CAUTION: Use caution when operating near loose
gravel or areas where loose debris may be
encountered.
Trimming adjustments are used to edge and trim in hard to reach
places. To begin using trimming adjustments:
1. Loosen the right axle nut located on the bottom of the
trimmer directly behind the axle shaft.
2. Lift the right wheel and pull back. The wheel and axle will
rotate backwards due to a slot cut in the bottom of the
trimmer frame.
3. Tighten the nut loosened in Step 1.
4. Push the trimmer slowly.
Models 73040/73050/73450 Trimming Adjustments
Model 73150 Self Propelled Operation
The Self Propelled EZ TrimMower is used in either push or self
propelled mode. Refer to previous section for general operation
instructions.
1. Pull self propelled bail (under handlebar) to start and stop self
propelled mode.
2. Adjust trimmer speed with throttle control if desired.
3. Operate EZ TrimMower safely and as intended.
Starting Instructions & Operation
Models 73450 & 74450
Move engine fuel valve to ON position before starting. See engine
manual complete instructions. See Figure 5.
3. Move the throttle control on the handlebar to the position.
Refer to Figure 6.
The choke may not be needed if the air temperature or engine is
warm. If so, move the throttle control slightly past the idle position.
Refer to the owners manual for other starting tips.
4. Pull the trimmer bail back.
5. Grasp the recoil starter cord handle and slowly pull until resistance
is felt. After resistance is felt, pull the cord quickly to start the
engine and prevent kickback. Repeat if necessary.
6. Move the throttle from to the (or high) position
after the engine warms up enough to operate without the choke.
7. Move the throttle level to the desired engine speed setting for
trimming.
Figure 6
Throttle Control
Figure 5
