TORQUE CHART
TORQUE (lubricated)
ITEM FREQUENCY* THREAD SIZE FT.-LB. Nm
(GRADE) MINIMUM MAXIMUM MINIMUM MAXIMUM
Boom Slide Bearings (front) 5 Weeks (250 hrs) 3/8-24 (5) 28 30 38 41
5 Weeks (250 hrs) 1/2-20 (5) 76 86 103 117
Boom Slide Bearings (rear) If front bearings have 3/8-24 (5) 28 30 38 41
worked loose 1/2-20 76 86 103 117
Boom Chain Jam Nuts Annually (1500 hrs) 7/8-14 100 110 136 149
Cab Mounting Bolts (upper) Annually (1500 hrs) 7/8-9 530 565 719 766
(lower) Annually (1500 hrs) 3/4-10 240 265 325 359
Engine Assembly
Flywheel Housing Bolts
Annually (1500 hrs) M10 53 58 72 79
Engine Pod to Frame Annually (1500 hrs) GR5 240 268 325 359
Front Axle Mounting Bolts Annually (1500 hrs) 3/4-10 545 595 739 807
Wheel Lug Nuts 3 Months (500 hrs) - 350 400 475 543
*Check torque at whichever interval occurs first.
To check GRADALL torque values, set the torque wrench at 95% of rated torque value and check fastener. If the
torque wrench releases before the fastener moves, assume fastener torque is correct. When setting GRADALL
torque values, use the values given on the following chart. Do not exceed allowances.
(hand) (hand)
RECOMMENDED LUBRICANTS & CAPACITIES
17.3
APPLICATION SYMBOL WHEN USED GRADE SPECIFICATION CAPACITY*
Boom Chain CL (chain lube) All Year - P/N 1440-4751 - -
Boom Bearing Paths HM (extreme pres. lube) All Year NLGI #2 P/N 1440-4818 - -
Coolant Additive (SCA supplemental All Year - - 0.5 qts 0.48 L
(refer to engine man.) coolant additive)
Transfer Case HF (hydraulic fluid) All Year ** ** 0.8 qts 0.8 L
Transmission HF (hydraulic fluid) All Year ** ** 16.7 qts 15.8 L
Engine Cooling System AF (anti-freeze) All Year 50/50 Permanent 15.5 qts 14.7 L
Engine Crankcase EO (engine oil) All Year 15W-40-CD MIL-L-2104D 14.5 qts 13.8 L
Front/Rear Axle
Center Section HF (hydraulic fluid) All Year ** ** 31.5 pints 14.9 L
Each Wheel End HF (hydraulic fluid) All Year ** ** 2.8 pints 1.3 L
Fuel Tank DF (diesel fuel) All Year #2 - 38 gal 143.8 L
Grease Fittings HM (extreme pres. lube) All Year NLGI #2 P/N 1440-4818 - -
Hydraulic System HF (hydraulic fluid) All Year *** *** 43 gal 163 L
* Capacities are approximate - check level to be sure.
** Fill to level using Mobilfluid ® 424 (GRADALL P/N 1440-4535)
*** Fill to level using Mobilfluid ® 424 -OR- Citgo Tractor Hydraulic Fluid (product code 33310)
When replacing foam filled tires, replace the complete tire
and rim assembly.
CAUTION !
