JLG G9-43A (9151-4003) Operator Manual User Manual

Page 14

2.2

Figure 2-3

S/N 0160000683 thru Current

9150-3108

Warning Decal, Steered Wheels

9150-3097

Warning Decal, Moving Parts

9151-3198

Oil Level Decal

9151-3209

Hydraulic Fluid Decal

7733-3027

Made in USA Decal

9150-3109

Warning Decal, No Riders

1701505

Diesel Fuel Decal

9151-3192

Service Instruction Plate

9150-3099

Warning Decal, Battery

9150-3102

Boom Control Decal

9150-3110

Danger Decal, High Voltage

9150-3098

Warning Decal, Safe Operation

9151-3041

Serial No. & Attachment Plate

9151-3208

Warning Decal, Lifting Personnel

9141-3061

Ignition Switch Decal

9151-3207

Load Chart Cover

9151-3042

Capacity Chart

9150-3109 REV -

NO RIDERS. Riders could FALL OFF

machine causing death or serious injury.

9150-3108 REV -

MOVING PARTS could

crush causing death

or serious injury.

Keep clear of wheels and

moving parts while engine

is running.

9150-3108 REV -

MOVING PARTS could

crush causing death

or serious injury.

Keep clear of wheels and

moving parts while engine

is running.

9150-3108 REV -

MOVING PARTS could

crush causing death

or serious injury.

Keep clear of wheels and

moving parts while engine

is running.

9150-3108 REV -

MOVING PARTS could

crush causing death

or serious injury.

Keep clear of wheels and

moving parts while engine

is running.

9151-3209 REV -

9150-3097 REV. -

MOVING PARTS can

cut or entangle. Keep

clear while engine is

running.

9151-3198 REV -

VIEW A-A

VIEW INSIDE

ENGINE COVER

VIEW OF DECALS INSIDE CAB

ON RIGHT HAND WALL

3 4

9151-3208 REV -

When lifting personnel, USE ONLY a Gradall manufactured

personnel work platform, with proper personnel work

platform CAPACITY CHART DISPLAYED in cab.

READ AND UNDERSTAND personnel work platform Owner/Operator

manual before lifting personnel.

DO NOT DRIVE machine from cab when personnel are on platform.

All personnel on platform must WEAR A FULL BODY HARNESS,

with lanyard attached to a designated anchorage point.

When personnel are on platform, the OPERATOR MUST REMAIN

SEATED in cab with personnel in direct line of sight.

OPERATE CONTROLS CAUTIOUSLY and lightly when lifting or

positioning personnel.

Failure to comply could result in death or serious injury.

5. On inclines, travel with load up-grade.

9. Level machine before lifting any load above 4 feet (1.2m).

9150-3098 REV. A

1. Only trained and authorized personnel may operate this

machine.

2. Before operating, read and understand all capacity charts,

operator manual and safety manuals.

3. Operator must be seated with seat belt fastened. Assure all

controls are in neutral before ignition switch is turned on.

4. Do not travel with boom raised. When traveling, fully

retract boom and place forks in carry position, which is

approximately 4 feet (1.2 m) above ground. Tilt carriage

back slightly to cradle load. Use extreme caution when

turning.

6. Keep others away from machine when operating. Do not

allow others to stand under boom or load. Always look in

direction of travel.

7. Use extreme care when handling long, high or wide loads.

Do not handle unstable or loosely stacked loads.

8. Forks must be centered under load, and spaced apart as far

as possible.

10. Improper use of machine could result in machine tipping

over. If machine starts to tip over, do not leave operator's

seat. Lean away from tip, and brace yourself.

11. Keep mirror(s) clean and properly adjusted. Objects in

mirror(s) are closer than they appear.

For safe operation of machine, and to minimize risk of

serious injury, READ AND OBSERVE the following:

9.0

26,140

26,310

26,500

0.8'

1.5'

25,530

25,700

25,880

25,920

25,750

25,930

25,870

26,060

27,000

27,100

27,800

26,800

25,960

28,080

CAP#

X1000

24"

AS RELEASED FROM FACTORY THIS TRUCK MEETS THE DESIGN SPECIFICATIONS

ESTABLISHED IN AMERICAN NATIONAL STANDARDS FOR POWERED INDUSTRIAL

TRUCKS PART III ASME B56.6b-1998.

ATTACHMENT

TRUCK &

ATTACHMENT

WEIGHT

24"

9.0

26,030

CAP#

1000

9151-3041 (A)

24"

0.8'

36'

40'

43'

24"

0.8'

2.3'

3.6'

24"

24"
24"

24"

9.0

8.0

7.0

4.0

4.5

2.0

6.0

4.0

9.0

2.0

---

24"

---

43'

53'

58'

43'

44'

34'

40'

---

5.7'

6.3'

5.7'

5.2'

5.7'

4.5'

3.6'

1.4'

4.5'

CAPACITY WITH STANDARD

48" & 72" CARRIAGE.

GRADALL IS A REGISTERED TRADEMARK

FOR HYDRAULIC EQUIPMENT

BUILT BY THE JLG COMPANY

1 JLG DRIVE, McCONNELLSBURG, PA.

U.S.A.

SHIPPED

WITH

*WEIGHTS ARE BASED ON USING 1 3/4 X 6 X 48" FORKS (APPROX. 350# PER PAIR)

**BUCKET DIMENSIONS (A & D) REFER TO BUCKET LIP HEIGHT.

***TRUSS BOOM & WINCH DIMENSIONS (A & D) REFER TO HOOK CENTER.

****WEIGHT IS BASED ON SP'L SWING MAST FORKS (48": APPROX. 230# PER PAIR)

(60": APPROX. 488# PER PAIR)

*****PLATFORM DIMENSIONS (A & D) REFER TO CENTER OF FLOOR.

ADD 2170 LBS TO MACHINE WEIGHTS WHEN EQUIPPED WITH

13.00 X 24 FOAM FILLED TIRES.

FORKS RATED LESS THAN THE ATTACHMENT CAPACITY SHOWN ABOVE DECREASE CAPACITY

OF ATTACHMENT TO THAT OF FORKS. FORKS RATED MORE THAN ATTACHMENT

CAPACITY DO NOT INCREASE ATTACHMENT CAPACITY.

25,200 LBS

10FT TRUSS BOOM W/WINCH

P/N 9140-5081 ***

15FT TRUSS BOOM W/WINCH

P/N 9140-5080 ***

6 FT SW. MAST W/48" FORKS

P/N 9140-5070 ****

6 FT SW. MAST W/60" FORKS

P/N 9141-5026 ****

60" 3/4 YD BUCKET

P/N 9140-5054 **
74" 1 1/4 YD BUCKET

P/N 9140-5055 **
102" 1 1/4 YD BUCKET

P/N 9140-5071 **
10FT TRUSS BOOM

P/N 9140-5083 ***

15FT TRUSS BOOM

P/N 9140-5082 ***

6FT MAST W/72" CARR.

P/N 9140-5061 *

72" 100° SWING CARR.

P/N 9140-5075 *
WORK PLATFORM

P/N 9141-5025 *****

6FT MAST W/48" CARR.

P/N 9140-5060 *

WINCH

P/N 9151-5036 ***

48" CARRIAGE

P/N 9140-5073 *
72" CARRIAGE

P/N 9140-5074 *
48" SLOPE PILER

P/N 9140-5101 *
72" SLOPE PILER

P/N 9140-5079 *

(WITHOUT

ATTACHMENTS)

9150-3110 REV A

10 FT.

(3 M)

CONTACTING ELECTRIC POWER

LINES will result in death

or serious injury.

Do not place machine or load

within 10 feet (3 m) of electric

power lines.

9150-3102 REV. -

WORK PLA

TFORM

6 FT

. MAST

48" & 72" CARRAIGE

100° SWING CARRIAGE

9151-3207 REV.-

The operator MUST:
1. Make sure the handler is on a firm, level surface

before lifting or placing a load.

2. Make sure that the capacity charts are for the

appropriate Gradall model.

3. Make sure that the Part Numver shown on the

attachment's Serial Number Plate matches the Part

Number shown on the capacity chart.

4. Be sure of the WEIGHT of the load to be lifted.

TIPOVER HAZARD. Failure to comply with

instructions could result in death or serious

injury.

Instructions
