Form No. 20127 • G9-43A Owner/Operator Manual
2.3
Figure 2-4
S/N 0160000683 thru Current
18 9151-3210 Warning Decal, Pinch Point
19 9151-3043 G9-43A Decal
20 9147-3132 JLG/Gradall Decal
21 9114-3282 Warning Decal, Pinch Point
22 9100-3031 Boom Angle Decal
23 9100-3016 “1” Decal
24 9100-3018 “2” Decal
25 9112-3042 “3” Decal
26 9100-3020 “4” Decal
27 9112-3044 “5” Decal
28 9116-3077 “6” Decal
14
22
9151-3210 REV -
MOVING P AR TS could cut or crush causing death or serious injury
. Keep clear of
moving p art s while engine is running.
9151-3208 REV -
When lifting personnel, USE ONLY a Gradall manufactured personnel work platform, with proper personnel work platform CAPACITY CHART DISPLAYED in cab. READ AND UNDERSTAND personnel work platform Owner/Operator manual before lifting personnel. DO NOT DRIVE machine from cab when personnel are on platform. All personnel on platform must WEAR A FULL BODY HARNESS, with lanyard attached to a designated anchorage point. When personnel are on platform, the OPERATOR MUST REMAIN SEATED in cab with personnel in direct line of sight. OPERATE CONTROLS CAUTIOUSLY and lightly when lifting or positioning personnel. Failure to comply could result in death or serious injury.
9151-3210 REV - MOVING PARTS could cut or crush causing death or serious injury. Keep clear of moving parts while engine is running.
9114-3282 STAY CLEAR OF PINCH POINT AREA ANYTIME ENGINE IS RUNNING. BEING IN PINCH POINT AREA COULD CAUSE SERIOUS INJURY OR DEATH.
9114-3282
STAY CLEAR OF PINCH POINT AREA ANYTIME ENGINE IS RUNNING. BEING IN PINCH POINT AREA COULD CAUSE SERIOUS INJURY OR DEATH.
9151-3210 REV - MOVING PARTS could cut or crush causing death or serious injury. Keep clear of moving parts while engine is running.
0°
9151-3210 REV - MOVING PARTS could cut or crush causing death or serious injury. Keep clear of moving parts while engine is running.
19 18 20
21
19 18 20
21
23 24 25 18 26 27 28
18
VIEW B-B
B B
