Form No. 20127 • G9-43A Owner/Operator Manual
2.1
Figure 2-2
S/N 0193001 thru 0160000668
D D
32 33
34
12
35
0°
26 27 28 29 30 31 25
20
21
1
22 23
24
25
25
VIEW D-D
20 9055-3026 Warning Decal, Lifting Personnel
21 9114-3290 Warning Decal, Attachment
22 9100-3031 Boom Angle Decal
23 9147-3132 JLG/Gradall Decal
24 9151-3043 G9-43A Decal
25 8060-3037 Warning Decal, Pinch Point
26 9100-3016 “1” Decal
27 9100-3018 “2” Decal
28 9112-3042 “3” Decal
29 9100-3020 “4” Decal
30 9112-3044 “5” Decal
31 9116-3077 “6” Decal
32 9055-3028 Warning Decal, Safe Operation
33 9151-3041 Serial No. and Attachment Plate
34 9140-3525 Boom operation Decal
35 9151-3192 Serice Instruction Plate
