SECTION 6 - JLG CONTROL SYSTEM
3121198 – JLG Lift – 6-35
ACCESSORY FAULT 144 6-7 9
CHASSIS TILT SENSOR NOT
CALIBRATED 145 8-1 9
POWER MODULE FAILURE:
PERSONALITY RANGE
ERROR 146 9-9 9 Lift Up, Swing Left, Swing Right, Tele-
scope In, Telescope Out, Jib Up, Level
Up, Level Down, Front Left L/J, Front
Right L/J, Rear Left L/J, Rear Right L/J,
Set (Extend L/J), Stow (Retract L/J) Lift Up, Swing Left, Swing Right, Tele-
scope In, Telescope Out, Jib Up, Level
Up, Level Down, Front Left L/J, Front
Right L/J, Rear Left L/J, Rear Right L/J,
Set (Extend L/J), Stow (Retract L/J)
POWER MODULE FAILURE:
INTERNAL ERROR 147 9-9 9 Lift Up, Swing Left, Swing Right, Tele-
scope In, Telescope Out, Jib Up, Level
Up, Level Down, Front Left L/J, Front
Right L/J, Rear Left L/J, Rear Right L/J,
Set (Extend L/J), Stow (Retract L/J) Lift Up, Swing Left, Swing Right, Tele-
scope In, Telescope Out, Jib Up, Level
Up, Level Down, Front Left L/J, Front
Right L/J, Rear Left L/J, Rear Right L/J,
Set (Extend L/J), Stow (Retract L/J)
POWER MODULE FAILURE:
CHECK POWER CIRCUITS
OR MOSFET SHORT CIR-
CUIT 148 9-9 9 Lift Up, Swing Left, Swing Right, Tele-
scope In, Telescope Out, Jib Up, Level
Up, Level Down, Front Left L/J, Front
Right L/J, Rear Left L/J, Rear Right L/J,
Set (Extend L/J), Stow (Retract L/J) Lift Up, Swing Left, Swing Right, Tele-
scope In, Telescope Out, Jib Up, Level
Up, Level Down, Front Left L/J, Front
Right L/J, Rear Left L/J, Rear Right L/J,
Set (Extend L/J), Stow (Retract L/J)
EEPROM FAILURE — CHECK
ALL SETTINGS 149 9-9 9 Lift Up, Lift Down, Swing Left, Swing
Right, Telescope In, Telescope Out, Jib
Up, Jib Down, Level Up, Level Down,
Front Left L/J, Front Right L/J, Rear Left
L/J, Rear Right L/J, Set (Extend L/J),
Stow (Retract L/J), Engine Start,
Engine Throttle Pull, Engine Throttle
Hold, Engine Choke Pull, Engine
Choke Hold Lift Up, Lift Down, Swing Left, Swing
Right, Telescope In, Telescope Out, Jib
Up, Jib Down, Level Up, Level Down,
Front Left L/J, Front Right L/J, Rear Left
L/J, Rear Right L/J, Set (Extend L/J),
Stow (Retract L/J), Engine Start,
Engine Throttle Pull, Engine Throttle
Hold, Engine Choke Pull, Engine
Choke Hold
FUNCTIONS LOCKED OUT —
PLATFORM MODULE SOFT-
WARE VERSION IMPROPER 150 9-9 9 Lift Up, Lift Down, Swing Left, Swing
Right, Telescope In, Telescope Out, Jib
Up, Jib Down, Level Up, Level Down,
Front Left L/J, Front Right L/J, Rear Left
L/J, Rear Right L/J, Set (Extend L/J),
Stow (Retract L/J), Engine Start,
Engine Throttle Pull, Engine Throttle
Hold, Engine Choke Pull, Engine
Choke Hold
FUNCTIONS LOCKED OUT —
POWER MODULE SOFT-
WARE VERSION IMPROPER 151 9-9 9 Lift Up, Swing Left, Swing Right, Tele-
scope In, Telescope Out, Jib Up, Level
Up, Level Down, Front Left L/J, Front
Right L/J, Rear Left L/J, Rear Right L/J,
Set (Extend L/J), Stow (Retract L/J) Lift Up, Swing Left, Swing Right, Tele-
scope In, Telescope Out, Jib Up, Level
Up, Level Down, Front Left L/J, Front
Right L/J, Rear Left L/J, Rear Right L/J,
Set (Extend L/J), Stow (Retract L/J)
Table 6-5. Help Messages
Help Message Index
Service
Flash
Code
User
Flash
Code
Function in Creep Mode
Function Locked Out from
Ground Control
Function Locked Out from
Platform Control
