SECTION 6 - JLG CONTROL SYSTEM
6-34
– JLG Lift –
3121198
FUNCTIONS AT CUTBACK --
POWER MODULE CURRENT
LIMIT
136
4-2
4
NO CHARGE SYSTEM OUT-
PUT
137
4-3
3
Lift Up, Lift Down, Swing Left, Swing
Right, Telescope In, Telescope Out, Jib
Up, Jib Down, Level Up, Level Down,
Front Left L/J, Front Right L/J, Rear Left
L/J, Rear Right L/J, Set (Extend L/J),
Stow (Retract L/J)
Lift Up, Lift Down, Swing Left, Swing
Right, Telescope In, Telescope Out, Jib
Up, Jib Down, Level Up, Level Down,
Front Left L/J, Front Right L/J, Rear Left
L/J, Rear Right L/J, Set (Extend L/J),
Stow (Retract L/J)
BATTERY VOLTAGE TOO
LOW — SYSTEM SHUT-
DOWN
138
4-4
5
Lift Up, Lift Down, Swing Left, Swing
Right, Telescope In, Telescope Out, Jib
Up, Jib Down, Level Up, Level Down,
Front Left L/J, Front Right L/J, Rear Left
L/J, Rear Right L/J, Set (Extend L/J),
Stow (Retract L/J), Engine Start,
Engine Throttle Pull, Engine Throttle
Hold, Engine Choke Pull, Engine
Choke Hold
Lift Up, Lift Down, Swing Left, Swing
Right, Telescope In, Telescope Out, Jib
Up, Jib Down, Level Up, Level Down,
Front Left L/J, Front Right L/J, Rear Left
L/J, Rear Right L/J, Set (Extend L/J),
Stow (Retract L/J), Engine Start,
Engine Throttle Pull, Engine Throttle
Hold, Engine Choke Pull, Engine
Choke Hold
BATTERY VOLTAGE TOO
HIGH — SYSTEM SHUT-
DOWN
139
4-4
5
Lift Up, Lift Down, Swing Left, Swing
Right, Telescope In, Telescope Out, Jib
Up, Jib Down, Level Up, Level Down,
Front Left L/J, Front Right L/J, Rear Left
L/J, Rear Right L/J, Set (Extend L/J),
Stow (Retract L/J), Engine Start,
Engine Throttle Pull, Engine Throttle
Hold, Engine Choke Pull, Engine
Choke Hold
Lift Up, Lift Down, Swing Left, Swing
Right, Telescope In, Telescope Out, Jib
Up, Jib Down, Level Up, Level Down,
Front Left L/J, Front Right L/J, Rear Left
L/J, Rear Right L/J, Set (Extend L/J),
Stow (Retract L/J), Engine Start,
Engine Throttle Pull, Engine Throttle
Hold, Engine Choke Pull, Engine
Choke Hold
CANBUS FAILURE: POWER
MODULE
140
6-6
9
Lift Up, Swing Left, Swing Right, Tele-
scope In, Telescope Out, Jib Up, Level
Up, Level Down, Front Left L/J, Front
Right L/J, Rear Left L/J, Rear Right L/J,
Set (Extend L/J), Stow (Retract L/J)
Lift Up, Swing Left, Swing Right, Tele-
scope In, Telescope Out, Jib Up, Level
Up, Level Down, Front Left L/J, Front
Right L/J, Rear Left L/J, Rear Right L/J,
Set (Extend L/J), Stow (Retract L/J)
CANBUS FAILURE: PLAT-
FORM MODULE
141
6-6
9
Lift Up, Lift Down, Swing Left, Swing
Right, Telescope In, Telescope Out, Jib
Up, Jib Down, Level Up, Level Down,
Front Left L/J, Front Right L/J, Rear Left
L/J, Rear Right L/J, Set (Extend L/J),
Stow (Retract L/J), Engine Start,
Engine Throttle Pull, Engine Throttle
Hold, Engine Choke Pull, Engine
Choke Hold
CANBUS FAILURE: DRIVE
MODULE
142
6-6
9
ACCESSORY CAN COMMU-
NICATION LOST
143
6-6
9
Table 6-5. Help Messages
Help Message
Index
Service
Flash
Code
User
Flash
Code
Function in Creep Mode
Function Locked Out from
Ground Control
Function Locked Out from
Platform Control
