SECTION 6 - JLG CONTROL SYSTEM
6-20
– JLG Lift –
3121198
PLATFORM LEVEL
ACCEL
0.1 to 5.0 sec
0.1
0.1
0.1
0.1
DECEL
0.1 to 3.0 sec
0.1
0.1
0.1
0.1
MIN UP
0 to 25% (75%)
12
53
12
53
MAX UP
0 to 50% (85%)
27
72
27
72
MIN DOWN
0 to 25% (75%)
12
53
12
53
MAX DOWN
0 to 50% (85%)
27
72
27
72
JIB LIFT
ACCEL
0.1 to 5.0 sec
N/A
N/A
2.5
2.5
DECEL
0.1 to 3.0 sec
N/A
N/A
0.8
0.8
MIN UP
0 to 25% (75%)
N/A
N/A
14
50
MAX UP
0 to 50% (85%)
N/A
N/A
26
62
N/A
N/A
20-25
20-25
MIN DOWN
0 to 25% (75%)
N/A
N/A
14
15
MAX DOWN
0 to 50% (85%)
N/A
N/A
28
46
N/A
N/A
13-18
15-21
LEVELING JACKS
ACCEL
0.1 to 5.0 sec
0.5
0.5
0.5
0.5
DECEL
0.1 to 3.0 sec
0.5
0.5
0.5
0.5
MIN SET
0 to 25% (75%)
10
65
10
65
MAX SET
0 to 100% (85%)
100
85
100
85
MIN STOW
0 to 25% (75%)
10
65
10
65
MAX STOW
0 to 100% (85%)
100
85
100
85
*
See Section 6.9 for orientation when setting speeds
Note 1: Personality settings can be adjusted anywhere within the adjustment range in order to achieve optimum machine performance.
Note 2: Stop watch should start when function starts.
Note 3: Unless noted, function speeds should be measured from the platform with one operator.
Note 4: All test should be done with the oil temp above 65 F (15.5 C).
Note 5: Ranges shown in "( )" are exceptions for Gas-powered machines.
Note 6: With swing motor P/N 3160182 optimum performance is achieved with these settings:
SWING, MAX (RT OR LT) : T350 electric = 21 - 25%, T350 gas = 66%, time = 65-80 seconds
SWING, MAX (RT OR LT) : T500J electric = 18%, T500J gas = 61%, time = 85-105 seconds
With swing motor P/N 3160331 optimum performance is achieved with these settings:
SWING, MAX (RT OR LT) : T350 electric = 30%, T350 gas = 60%, time = 65-85 seconds
SWING, MAX (RT OR LT) : T500J electric = 34%, time = 75-95; T500J gas = 60%, time = 65-85 seconds
4150561-G
Table 6-2. Machine Model Adjustments and Speeds - ANSI & CSA
FUNCTION
ADJUSTMENT
1,4
MODEL DEFAULTS
MODEL TIME RANGE (SECONDS)
2,3
RANGES
5
T350
Electric
T350 Gas
T500J
Electric
T500J
Gas
T350
Electric
T350 Gas
T500J
Electric
T500J Gas
