SECTION 6 - JLG CONTROL SYSTEM
3121198 – JLG Lift – 6-19
Table 6-2. Machine Model Adjustments and Speeds - ANSI & CSA
FUNCTION
ADJUSTMENT 1,4 MODEL DEFAULTS MODEL TIME RANGE (SECONDS) 2,3
RANGES
5
T350
Electric
T350 Gas
T500J
Electric
T500J
Gas
T350
Electric
T350 Gas
T500J
Electric
T500J Gas
DRIVE
FORWARD (25’ COURSE) 20-28 19-22 20-28 19-22
REVERSE (25’ COURSE) 20-28 19-22 20-28 19-22
ACCEL 0.1 to 5.0 sec 1.0 1.0 1.0 1.0
DECEL 0.1 to 3.0 sec 0.5 0.5 0.5 0.5
L FWD MIN 0 to 100% 15 15 15 15
L FWD MAX 0 to 100% 50 50 50 50
L REV MIN 0 to 100% 15 15 15 15
L REV MAX 0 to 100% 50 50 50 50
R FWD MIN 0 to 100% 15 15 15 15
R FWD MAX 0 to 100% 50 50 50 50
R REV MIN 0 to 100% 15 15 15 15
R REV MAX 0 to 100% 50 50 50 50
LIFT
ACCEL 0.1 to 5.0 sec 1.5 1.5 2.5 2.5
DECEL 0.1 to 3.0 sec 0.8 0.8 0.8 0.8
MIN UP 0 to 25% (75%) 6 56 3 56
MAX UP 0 to 100% (85%) 80 72 80 72 24-34 24-34 40-50 40-50
MIN DOWN 0 to 25% (50%) 11 25 14 25
MAX DOWN 0 to 35% (65%) 27 46 26 46 26-36 26-36 35-46 35-46
CREEP 0 to 50% 50 50 50 50
SWING
ACCEL 0.1 to 5.0 sec 2.7 2.7 2.7 2.7
DECEL 0.1 to 3.0 sec 1.0 1.0 1.0 1.0
MIN LEFT 0 to 25% (75%) 4 58 4 50
MAX LEFT 0 to 50% (85%) 35 63 35 63 55-85 55-85 65-105 65-105
MIN RIGHT 0 to 25% (75%) 4 58 4 50
MAX RIGHT 0 to 50% (85%) 35 63 35 63 55-85 55-85 65-105 65-105
CREEP 0 to 35% 30 30 30 30
TELESCOPE
ACCEL 0.1 to 5.0 sec 1.5 1.5 1.5 1.5
DECEL 0.1 to 3.0 sec 0.8 0.8 0.8 0.8
MIN IN 0 to 25% (75%) 5 57 1 57
MAX IN 0 to 100% (85%) 100 80 80 72 17-23 15-21 19-26 19-26
MIN OUT 0 to 25% (75%) 10 60 10 60
MAX OUT 0 to 100% (85%) 60 80 100 80 17-23 13-19 19-26 19-26
CREEP 0 to 35% 30 30 30 30
