SECTION 1 - SPECIFICATIONS
3121198
– JLG Lift –
1-1
SECTION 1. SPECIFICATIONS
1.1 OPERATING SPECIFICATIONS
1.2 CAPACITIES
1.3 ELECTRIC POWER UNIT
1.4 TIRES
Table 1-1. Operating & Towing Specifications
Tongue Weight (ANSI):
252 lbs.(114 kg)
Maximum Allowable Tow Speed:
(Do NOT exceed legal speed limit)
65 mph
(105 kph)
Maximum Work Load (Capacity)
w/Rotator
440 lbs.
(200 kg)
Maximum Work Load (Capacity)
w/o Rotator
500 lbs.
(230 kg)
Maximum Work Load (Capacity)
w/Rotator & Panel Tray
320 lbs.
(145 kg)
Maximum Work Load (Capacity)
w/o Rotator & w/Panel Tray
350 lbs.
(158 kg)
Material Hook Capacity (Optional)
500 lbs.(230 kg)
Accessory Tray Capacity
250 lbs.
*
(114 kg)
Panel Tray Capacity (w/Rotator)
70 lbs. (32 kg)
Panel Tray Capacity (w/o Rotator)
100 lbs. (45 kg)
Swing
410°
non-continuous
Max.Vertical Platform Height (Unrestricted)
35 ft. (10.6 m)
Vertical Reach (unrestricted)
35 ft. (10.4 m)
Horizontal Reach
(from centerline of machine)
(from outrigger pad edge)
20 ft. (6.1 m)
14 ft. (4.27 m)
Up and Over Clearance
15 ft. (4.57 m)
Maximum Outrigger Load
1950 lbs. (884.5 kg)
Maximum Ground Bearing Pressure
22.5 psi (1.58 kg/cm
2
)
Maximum Travel Gradeability - ANSI, CSA,
AUS
20%
Maximum Travel Gradeability - CE
15%
Maximum Sideslope - ANSI, CSA, AUS
11°
Maximum Sideslope - CE
8.5°
Maximum Horizontal Manual Force
90 lb. force (400 N)
Electrical System Voltage - Electric Machine
24 volts
Electrical System Voltage - Gas Machine
12 volts
Gross Machine Weight
(Platform Empty)
ANSI/CSA/Australian Machines
3330 lbs. (1510 kg)
Gross Machine Weight
(Platform Empty)
CE Machines
3748 lbs. (1700 kg)
*
DO NOT exceed axle rating or GVW rating.
Table 1-2. Capacities
Fuel Tank
1.6 Gal. (6.0 L)
Hydraulic Tank
Filling Volume
Usable Volume
4.4 Gallon (16.65 Liters)
4.0 Gallon (15.1 Liters)
Engine Crankcase
1.16 qt. (1.0 Liter)
Table 1-3. Electric Power Unit Specifications
@ 740PSI
(51 Bar)
@1500PSI
(103 Bar)
@ 3000PSI
(207 Bar)
Motor
Power
3.0 kW
3.0 kW
3.0 kW
Voltage
24 VDC
24 VDC
24 VDC
Amperage
90
140
230
Speed
4000 rpm 3600 rpm
2900 rpm
Short Term
Operation
9 min-
utes
6 min-
utes
2 minutes
Intermittent
Operation
28%
19%
10%
Pump
Flow Rate
3.0 gpm
(11.3
lpm)
2.7 gpm
(10.2
lpm)
2.2 gpm
(8.3 lpm)
Displace-
ment
0.192 cu.in.
(3.15 cc)
Table 1-4. Tire Specifications
(ANSI)
(CE)
Size
205-R14
185-R14C
Load Rating
1760 lbs. @ 50
psi
(798 kg @ 345
kPa)
1984 lbs. @ 65
psi
(900 kg @450
kPa)
Ply Rating/Load Range
6/C
8/D
Weight
36 lbs. (16 kg)
36 lbs. (16 kg)
Speed
Category
- -
S
Inflation Pressure
50 psi (345 kPa)
Wheel Nut Torque
90-120 ft. lbs.
(122-164 Nm)
66 ft. lbs.
(90 Nm)
