SECTION 6 - JLG CONTROL SYSTEM
6-24 – JLG Lift – 3121198
Table 6-4. Machine Configuration Programming Information
Configuration
Digit
Setting Description Market Default
0 1 2 3 4
1
(MODEL#)
0
1 T350 - 35ft.
T500 - 50ft. 0
2
(POWER)
0
1 Electric - 24V Battery
Engine - Honda Gasoline
0
3
(DRIVE)
3
0
1 NO - Drive option not installed.
YES - Drive option is installed.
0
4
(MARKET)
0
1
2
3
4 ANSI USA
ANSI EXPORT
CSA
CE
AUSTRALIA
0
5
(GROUND
ALARM)
0
1
2
Not installed - Optional Ground Alarm shall not sound
Descent - Optional Ground Alarm shall sound for 1000mS On, 1000mS Off during lift
down operations.
MOTION - Optional Ground Alarm shall sound for 1000mS On, 1000mS Off during
drive, lift, swing, telescope, level jib and L/J operations.
1 1 1 1
Notes: 1. When configuring a T-Series vehicle, the Machine Configuration must be completed before any Personality settings can be changed.
Changing the Personality settings first and then changing the Model of the Machine Configuration will cause the Personality settings to return to default
values.
2. Shaded entries are not available (adjustable) for the selected Market
3. DRIVE Machine Configuration Setting only available when POWER is set to 1=ENGINE (Ground Module Version P1.3).
4150562-B
