JLG 1850SJ Parts Manual - Manual (Page 341)

3121620 1850SJ 8-59
SECTION 8 ELECTRICAL
1001149971_PG 4 OF 4
ITEM 23 - EIC
CONNECTOR PART NUMBER: 1001126362
CONN
POS
WIRE WIRE
LABEL
GAUGE TO
1 SHLD 0.75 mm²
2 BLK 148-70 STRT GND 0.75 mm²
3 BLK 148-71 STRT SIG 0.75 mm²
4
5
6
7
8
9 SHLD 0.75 mm²
10
11
12
13 BLK 0.75 mm²
14 BLK 0.75 mm²
15 BLK 0.75 mm²
16
17 BLK 0.75 mm²
18
19 BLK 1.5 mm²
20 BLK 1.5 mm²
21 BLK 0.75 mm²
22 BLK 0.75 mm²
23 BLK 0.75 mm²
24 BLK 0.75 mm²
25 BLK 0.75 mm²
26 BLK 248-44 OIL PRESS 0.75 mm²
27 BLK 248-29 OIL PRESS 0.75 mm²
28 BLK 0.75 mm²
29 BLK 0.75 mm²
30
31 BLK 0.75 mm²
32 BLK 0.75 mm²
33
34 BLK 0.75 mm²
35 BLK 248-16 INJECTOR 1 1.5 mm²
36
37 BLK 248-18 INJECTOR 4 1.5 mm²
38 BLK 248-32 INJECTOR 3 1.5 mm²
39
40 BLK 248-46 INJECTOR 2 1.5 mm²
41 BLK 248-3 INJECTOR 2 1.5 mm²
42 BLK 248-48 INJECTOR 4 1.5 mm²
43
44
45
46 BLK 0.75 mm²
47 BLK 1.5 mm²
48 BLK 1.5 mm²
49 BLK 0.75 mm²
50 BLK 0.75 mm²
51 BLK 0.75 mm²
52 BLK 0.75 mm²
53- 60 NOT USED
61 BLK 248-2 INJECTOR 3 1.5 mm² ECM-J2 (2)
62 BLK 248-33 INJECTOR 1 1.5 mm²
ITEM 24 - ECM-J2
CONNECTOR PART NUMBER: 1001133957
CONN
POS
WIRE WIRE
LABEL
TO
1
2 BLK 248-2 INJECTOR 3 EIC (61)
3 BLK 248-3 INJECTOR 2 EIC (41)
4 BLK 248-4MPROP ACTUATOR EIC (19)
5 BLK 248-5MPROP ACTUATOR EIC (20)
6
7 BLK EIC (32)
8
9
10
11
12
13
14
15
16
BLK 248-16
GAUGE
1.5 mm²
1.5 mm²
1.5 mm²
1.5 mm²
0.75 mm²
INJECTOR 1 1.5 mm² EIC (35)
17
18
BLK 248-18 INJECTOR 4 1.5 mm² EIC (37)
19 BLK 248-19 EXH GAS RECIRC 1.5 mm² EIC (47)
20 BLK 248-20 EXH GAS RECIRC 1.5 mm² EIC (48)
21
22
23 BLK 248-23 GLOW SENSE 0.75 mm²
24 BLK 0.75 mm² EIC (22)
25 BLK 248-25 RAIL PRESS FUEL 0.75 mm² EIC (31)
26 BLK 248-26 RAIL PRESS FUEL 0.75 mm² EIC (25)
27 BLK 0.75 mm² EIC (29)
28 BLK 248-28 COOLING TEMP 0.75 mm² EIC (24)
29 BLK 248-29 OIL PRESS 0.75 mm² EIC (27)
30
31
32 BLK 248-32 INJECTOR 3 1.5 mm² EIC (38)
33 BLK 248-33 INJECTOR 1 1.5 mm² EIC (62)
34
35 BLK 0.75 mm²
36
37 BLK 248-37 ENG SPD CMSHFT 0.75 mm² EIC (14)
38 SHLD 0.75 mm² EIC (1)
39 BLK 0.75 mm² EIC (15)
40 BLK 248-40 AIR INLET TEMP 0.75 mm² EIC (28)
41
42
43 BLK 248-43 OIL PRESS 0.75 mm² EIC (23)
44 BLK 248-44 OIL PRESS 0.75 mm² EIC (26)
45
46 BLK 248-46 INJECTOR 2 1.5 mm² EIC (40)
47
48 BLK 248-48 INJECTOR 4 1.5 mm² EIC (42)
49
50
51
52 BLK 248-52 ENG SPD CMSHFT 0.75 mm² EIC (13)
53 SHLD 248-53 0.75 mm² EIC (9)
54 BLK 0.75 mm² EIC (21)
55-60 NOT USED
