JLG 1850SJ Parts Manual - Manual (Page 315)

3121620 1850SJ 8-33
SECTION 8 ELECTRICAL
ITEM 7 - HV105 LIFT DN AUX
CONNECTOR PART NUMBER: 4460891
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE TO
1 WHT 55-10 LFT DN AUX 18 AWG CO02-J2 (12)
2 BLK 0-6-3 18 AWG S155 (2)
CONNECTOR PART NUMBER: 4460891
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE TO
1 WHT 55-11 LFT PLT 18 AWG CO02-J2 (10)
2 BLK 0-10-1 18 AWG S154 (2)
ITEM 8 - HV107 LIFT PILOT
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE TO
1 WHT 22-1 SWG RHT 18 AWG CO02-J2 (32)
2 BLK 0-30-2 18 AWG S153 (2)
CONNECTOR PART NUMBER: 4460891
ITEM 9 - HV99 SWG RHT
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE TO
1 WHT 3-1 MLIFT DN 18 AWG CO02-J2 (22)
2 BLK 0-6-2 18 AWG S155 (2)
CONNECTOR PART NUMBER: 4460891
ITEM 10 - HV101 MAIN LIFT DN
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE TO
1 WHT 13-3 MTELE OUT 18 AWG CO02-J2 (16)
2 BLK 0-11-2 18 AWG S156 (2)
CONNECTOR PART NUMBER: 4460891
ITEM 11 - HV103 MAIN TELE OUT
ITEM 6 - X440A
CONNECTOR PART NUMBER: 4460930
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE TO
1 WHT 55-30 LFT ENABLE 18 AWG HV315 (1)
2 BRN 49-77 P C PWR 20 AWG SN438 (1)
3 BLK 49-76 P C GND 20 AWG SN438 (4)
4 BLU 49-75 PRS CHK 20 AWG SN438 (3)
5 BRN 49-73 L P PWR 20 AWG SN439 (1)
6 BLK 49-74 L P GND 20 AWG SN439 (4)
7 BLU 49-72 LIFT PRS 20 AWG SN439 (3)
8 SHLD RTN 20 AWG S455 (1)
ITEM 2 - HV348 SWG FLOW CNTRL
CONNECTOR PART NUMBER: 4460891
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE TO
1 WHT 55-32 SWG F.C. 18 AWG CO02-J2 (35)
2 WHT 60-3 SWG RTN 18 AWG CO02-J3 (4)
ITEM 3 - X159A
CONNECTOR PART NUMBER: 4460836
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE TO
1 WHT 27-3 JIB DN O/R 18 AWG
2 WHT 25-6 PLVL UP O/R 18 AWG CO02-J2 (5)
3 WHT 25-5 PLVL DN O/R 18 AWG CO02-J2 (7)
4 WHT 50-2 PLTFRM DUMP 16 AWG CO02-J2 (3)
5 WHT 50-3 JIB DUMP 16 AWG CO02-J2 (1)
6 WHT 49-45 HYD OIL TEMP 18 AWG SN416 (1)
7 BLK 0-31 18 AWG SN416 (2)
8
9
10
11 BLK 0-14 16 AWG S157 (1)
12 WHT 47-6 ALT EXC 18 AWG CO02-J3 (9)
CO02-J2 (31)
ITEM 1 - HV102 LIFT FLOW CNTRL
CONNECTOR PART NUMBER: 4460891
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE TO
1 WHT 55-9 LFT FCNTRL 18 AWG CO02-J2 (19)
2 WHT 60-1 LFCNTRL RTN 18 AWG CO02-J3 (1)
ITEM 4 - SN439
CONNECTOR & CABLE PART NUMBER: 1001163747
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE TO
1 BRN 49-73 L P PWR 20 AWG X440A (5)
2
3 BLU 49-72 LIFT PRS 20 AWG X440A (7)
4 BLK 49-74 L P GND 20 AWG X440A (6)
SHLD SHLD P LIFT SN 20 AWG S455 (2)
ITEM 5 - SN438
CONNECTOR & CABLE PART NUMBER: 1001163747
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE TO
1 BRN 49-77 P C PWR 20 AWG X440A (2)
2
3 BLU 49-75 PRS CHK 20 AWG X440A (4)
4 BLK 49-76 P C GND 20 AWG X440A (3)
SHLD SHLD P CHK SN 20 AWG S455 (2)
1001149974_PG 2 OF 4
