SECTION 8 ELECTRICAL
ITEM 19 - X375
CONNECTOR PART NUMBER: 4460256
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE
TO
1
BLK
0-22
14 AWG
X412 (1)
ITEM 20 - X237
CONNECTOR PART NUMBER: 4460256
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE
TO
1
BLK
0-14
18 AWG X159B (11)
1
BLK
0-16
18 AWG
LB417 (2)
ITEM 21 - RL236-Y
CONNECTOR PART NUMBER: 1001117106
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE
TO
1
YEL
2-10
14 AWG
X412 (2)
1
YEL
2-11
12 AWG CO02-J8 (2)
ITEM 23 - RL235-Y
CONNECTOR PART NUMBER: 1001117106
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE
TO
1
YEL
2-25
12 AWG
X81 (10)
1
YEL
2-26
12 AWG
X81 (12)
ITEM 24 - X353
CONNECTOR PART NUMBER: 4460043
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE
TO
1
YEL
2-12
18 AWG
X327B (5)
1
YEL
2-17
18 AWG
LB417 (1)
ITEM 25 - RL235-R
CONNECTOR PART NUMBER: 4460312
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE
TO
1
YEL
2-1-99 IGNITION
16 AWG
S372 (1)
1
YEL
2-13
16 AWG
X217A (5)
ITEM 26 - X147A
CONNECTOR PART NUMBER: 4460836
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE
TO
1
YEL
CAN HI
18 AWG MS148-2 (A)
2
GRN
CAN LO
18 AWG MS148-2 (B)
3
SHLD
CAN SHLD
18 AWG MS148-2 (C)
4
5
6
7
WHT
55-14 BRAKE
18 AWG CO02-J1 (23)
8
ITEM 22 - RL236-R
CONNECTOR PART NUMBER: 4460312
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE
TO
1
YEL
02-6
10 AWG
X149A (1)
ITEM 29 - BT361+
CONNECTOR PART NUMBER: 4460019
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE
TO
1
RED
1-7 WK LT PWR
12 AWG
IP379 (1)
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE
TO
1
WHT
27-3 JIB DN O/R
18 AWG
X81 (15)
2
WHT
25-6 PLVL UP O/R
18 AWG
X81 (9)
3
WHT
25-5 PLVL DN O/R
18 AWG
X81 (7)
4
WHT
50-2 PLTFM DUMP
16 AWG
X341A (4)
5
WHT
50-3 JIB DUMP
16 AWG
X341A (3)
6
WHT
49-45 HYD OIL TEMP 18 AWG CO02-J1 (35)
7
BLK
0-31
18 AWG CO02-J1 (27)
8
9
10
11
BLK
0-14
18 AWG
X237 (1)
12
WHT
47-6 ALT EXC
18 AWG
S371 (2)
ITEM 30 - X159B
CONNECTOR PART NUMBER: 4460950
ITEM 31 - X217A
CONNECTOR PART NUMBER: 4460931
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE
TO
1
YEL
2-1-99 IGNITION
18 AWG
S372 (2)
2
BLK
0-17
16 AWG CO02-J1 (8)
3
WHT
52-9 GEN
18 AWG CO02-J1 (22)
4
WHT
48-7 GLOW
18 AWG CO02-J1 (12)
5
YEL
2-13
16 AWG RL235-R (1)
6
BLK
0-18
18 AWG CO02-J1 (9)
7
WHT
48-8 SP
18 AWG CO02-J1 (7)
8
ITEM 27 - X149A
CONNECTOR PART NUMBER: 4461018
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE
TO
1
YEL
02-6
10 AWG RL236-R (1)
2
BLK
00-11
10 AWG
X418 (1)
ITEM 28 - IP379
CONNECTOR PART NUMBER: 2400066
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE
TO
1
RED
1-7 WK LT PWR
12 AWG BT361+ (1)
2
RED
1-7-1 WK LT PWR
16 AWG
X341A (2)
2
RED
1-7-2 WK LT PWR
16 AWG
X341A (1)
1001149972_PG 3 of 7
