1-12 1850SJ 3121620
SECTION 1 FRAME
48 See Note 2 Seal (Note: Use p/n 70004453 or 70004451)
49 See Note 2 O-Ring (Note: Use p/n 70004453 or 70004451)
50 See Note 1 Piston, Brake (Note: Use p/n 70004453)
51 See Note 5 Spring, Brake (Note: Use p/n 70004453)
52 See Note 1 Spacer (Note: Use p/n 70004453)
53 See Note 1 Ring, Retaining (Note: Use p/n 70004453)
54 See Note 1 O-Ring (Note: Use p/n 70004451)
55 70004449 1 Support, Motor
56 70004450 6 Screw M8 x 25
100 70004451 1 Kit, Seal (Includes Items 4, 7, 10, 26, 31, 33, 46-49 & 54)
101 70004452 1 Kit, Cover (Includes Items 2-10)
102 70004453 1 Kit, Brake (Includes Items 43-53)
FIGURE 1-5. DRIVE HUB ASSEMBLY (CONTINUED)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
