SECTION 1 - SPECIFICATIONS
3120718 – JLG Lift – 1-13
Table 1-12. Lubrication Chart - S Models
Components
Number/Type
Lube Points
Capacity Lube
Interval Hours
Comments
3 Months
150 hrs
6 Months
300 hrs
1 Year
600 hrs
2 Years
1200 hrs
Lubrication
1 Swing Bearing 2 Grease Fittings A/R MPG X Remote Access
2 Steer Spindles (2WS)* 8 Grease Fittings A/R MPG X
3 Steer Spindles (4WS)* 2 Grease Fittings A/R MPG X
4 Steer Spindles (4WD)* 4 Grease Fittings A/R MPG X
5 Wheel Bearings Repack A/R MPG X
6 Swing Drive Hub Level/Fill Plug 17 oz. (1/2 Full) EPGL X Check level every 150 hrs/change 1200 hours
7 Wheel Drive Hub Level/Fill Plug 17 oz. (1/2 Full) EPGL X Check level every 150 hrs/change 1200 hours
8 Hydraulic Return Filter N/A N/A N/A X Change after first 50 hrs. and every 300 hrs.
thereafter or as indicated by Condition Indica-
tor.
9 Hydraulic Charge Filter N/A N/A N/A X Change after first 50 hrs. and every 300 hrs.
thereafter or as indicated by Condition Indica-
tor.
10 Hydraulic Oil Fill Cap 30.6 gal. Tank
32.7 gal. System
HO X Check level daily/change 1200 hours
11 Suction Strainers (in
tank) 2 N/A N/A X Remove and clean at time of hydraulic oil
change.
Engines
12 Oil Change w/Filter -
Ford LRG423 Fill Cap/Spin-on Element 5 Quarts EO X Check level daily/Change in accordance with
engine manual.
13 Oil Change w/Filter -
Ford LRG425 Fill Cap/Spin-on Element 4.5 Quarts EO X Check level daily/Change in accordance with
engine manual.
14 Oil Change w/Filter -
Continental Fill Cap/Spin-on Element 6 Quarts EO X Check level daily/Change in accordance with
engine manual.
15 Oil Change w/Filter -
Deutz Fill Cap/Spin-on Element 11 Quarts Crankcase
**5 Quarts Cooler
EO X Check level daily/Change in accordance with
engine manual.
16 Oil Change w/Filter -
Caterpillar Fill Cap/Spin-on Element 10.6 Quarts EO X Check level daily/Change in accordance with
engine manual.
17 Fuel Filter - Ford Replaceable Element N/A N/A X
18 Fuel Filter - Continental Replaceable Element N/A N/A X
19 Fuel Filter - Deutz Replaceable Element N/A N/A X
20 Fuel Filter - Caterpillar Replaceable Element N/A N/A X
21 Air Filter - Ford Replaceable Element N/A N/A X Or as indicated by Condition Indicator.
22 Air Filter - Continental Replaceable Element N/A N/A X Or as indicated by Condition Indicator.
23 Air Filter - Deutz Replaceable Element N/A N/A X Or as indicated by Condition Indicator.
24 Air Filter - Caterpillar Replaceable Element N/A N/A X Or as indicated by Condition Indicator.
