SECTION 1 - SPECIFICATIONS
1-10 – JLG Lift – 3120718
1.10 CRITICAL STABILITY WEIGHTS
DO NOT REPLACE ITEMS CRITICAL TO STABILITY WITH ITEMS
OF DIFFERENT WEIGHT OR SPECIFICATION (FOR EXAMPLE:
BATTERIES, FILLED TIRES, COUNTERWEIGHT, ENGINE & PLAT-
FORM) DO NOT MODIFY UNIT IN ANY WAY TO AFFECT STABIL-
ITY.
Table 1-10. Critical Stability Weights (S Models)
600SJ 660SJ 600S
LB. KG. LB. KG. LB. KG.
Tire and Wheel (Ballasted Only) Size (15 - 19.5) 253 115 253 115 253 115
Engine Ford 460 209 460 209 460 209
Deutz 534 242 534 242 534 242
Continental 558 253 558 253 558 253
Counterweight Weight 3500 1588 4650 2109 2900 1315
Platform 6 ft. (1.83 M) 205 93 205 93 205 93
8 ft. (2.44 M) 230 105 230 105 230 105
Table 1-11. Critical Stability Weights (A Models)
600AJ 600A
LB. KG. LB. KG.
Tire and Wheel (Ballasted Only) Size (14-17.5) 165 75 165 75
Engine Ford 460 209 460 209
Deutz 534 242 534 242
Continental 558 253 558 253
Counterweight Weight 6200 2812 5700 2586
Platform 6 ft. (1.83 M) 205 93 205 93
8 ft. (2.44 M) 230 105 230 105
