JLG 41EL Parts Manual - Manual (Page 65)

3120783 3-19
SECTION 3 MAST
S
E
C
T
I
O
N
3
M
A
S
T
203 3311605 Locknut 3/8”-16NC 4
204 4711600 Washer 3/8” 8
205 4845717 Stowage Rack Weldment (Left Side) 1
206 4845728 Stowage Rack Weldment (Right Side) 1
0258448 OPTIONAL CRANE HOOK INSTALLATION Ref. C
301 0641612 Bolt 3/8”-16NC x 1 1/2” 4
302 3311605 Locknut 3/8”-16NC 4
303 3570976 Plate, Crane Hook 1
304 4711600 Flatwasher 3/8” 8
305 1703455 Decal - Crane Hook 1
0256559 SAFETY ATTACH INSTALLATION Ref. 3
401 4845345 Weldment, Safety Attach 1
402 3539814 Plate 1
403 0681812 Bolt 1/2”-13NC x 1 1/2” 2
404 3271805 Locknut 1/2”-13NC‘ 2
405 4751800 Flatwasher 1/2” 4
406 Decal - Lanyard Attach Options: 1
1702612 (Prior to S/N 18765)
1704277 (S/N 18765 to Present)
FIGURE 3-4. MAST MOUNTED COMPONENTS INSTALLATIONS (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
