JLG 41EL Parts Manual User Manual
Page 49
3120783
3-3
SECTION 3 MAST
S
E
C
T
I
O
N
3
M
A
S
T
.
FIGURE 3-1. MAST ASSEMBLY - 20EL
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
MAST ASSEMBLY - 20EL OPTIONS:
Ref.
0801141
(Prior to S/N 17519)
Ref.
H
0801291
(S/N 17519 to Present)
Ref.
C
1
0100011
Loctite #242 (Not Shown)
A/R
2
0362735
Bar, Sheave Pin Support
4
3
0362736
Bar, Sheave Pin Support
2
4
0362758
Bar, Gravity Latch
1
5
0641406
Bolt 1/4”-20NC x 3/4” 33
6
0641407
Bolt 1/4”-20NC x 7/8”
6
7
Bolt Options:
A/R
0641410
Bolt 1/4”-20NC x 1 1/4” (Prior to S/N 15661)
4
0681410
Bolt 1/4”-20NC x 1 1/4” (S/N 15661 to Present)
8
8
0641508
Bolt 5/16”-18NC x 1”
1
9
0641610
Bolt 3/8-16NC x 1 1/4”
2
10
0641618
Bolt 3/8”-16NC x 2 1/4”
4
11
0641812
Bolt 1/2”-13NC x 1 1/2”
4
12
0741606
Screw 3/8”-16NC x 3/4”
4
13
0902047
Bracket, Sequence Cable
1
14
0902423
Bracket, Bottom Chain Attach
1
15
0902424
Bracket, Bottom Chain Attach
2
16
0902431
Bracket, Sequence Cable
3
17
0902445
Bracket, Sequence Cable
3
18
0961892
Bushing, Flanged
2
19
1060683
Cable, Sequence
3
20
1060685
Cable, Extension
2
21
1060696
Cable, Extension
2
22
1260329
Chain Assembly - #466 (See Items 101-107 for Breakdown)
2
23
1271389
Channel, Mast #1
1
24
1271390
Channel, Mast #2
1
25
1271391
Channel, Mast #3
1
26
1271392
Channel, Mast #6
1
27
1271393
Channel, Mast Header
1
28
Lift Cylinder Assembly Options
(See Section 5 for Breakdown):
1
1683699
(Prior to S/N 17519)
1684088
(S/N 17519 to Present)
29
2880310
Key
3
30
3311405
Locknut 1/4”-20NC (Prior to S/N 12269)
3
3311401
Nut 1/4”-20NC (S/N 12269 to Present)
3
31
3311505
Locknut 5/16”-18NC
1
32
3311601
Nut 3/8”-16 NC
12
33
3311605
Locknut 3/8”-16NC
6
34
3340845
Pad, Slide Guide
14
35
Pad, Slide Guide Options:
2
Use 3340858
Prior to S/N 15661 (P/N was 3340846)
3340858
S/N 15661 to Present
36
3422717
Pin, Sheave
3
37
3570893
Plate, Cylinder Mount
2
