3120783 3-7
SECTION 3 MAST
S
E
C
T
I
O
N
3
M
A
S
T
.
FIGURE 3-2. MAST ASSEMBLY - 25EL & 36EL
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
MAST ASSEMBLIES OPTIONS: Ref.
0801142 25EL (Prior to S/N 17519) Ref. G
0801292 25EL (S/N 17519 to Present) Ref. C
0801144 36EL (Prior to S/N 17519) Ref. G
0801294 36EL (S/N 17519 to Present) Ref. C
1 0100011 Loctite #242 (Not Shown) A/R
2 0362735 Bar, Sheave Pin Support 6
3 0362736 Bar, Sheave Pin Support 2
4 0362758 Bar, Gravity Latch 1
5 0641406 Bolt 1/4”-20NC x 3/4” 42
6 0641407 Bolt 1/4”-20NC x 7/8” 8
7 Bolt Options: A/R
0641410 Bolt 1/4”-20NC x 1 1/4” (Prior to S/N 15661) 4
0681410 Bolt 1/4”-20NC x 1 1/4” (S/N 15661 to Present) 8
8 0641508 Bolt 5/16”-18NC x 1” 1
9 0641610 Bolt 3/8”-16NC x 1 1/4” 4
10 0641618 Bolt 3/8”-16NC x 2 1/4” 4
11 0641812 Bolt 1/2”-13NC x 1 1/2” 4
12 0741606 Screw 3/8”-16NC x 3/4” 4
13 0902047 Bracket, Sequence Cable 1
14 0902422 Bracket, Bottom Chain Attach 1
15 0902423 Bracket, Bottom Chain Attach 2
16 0902424 Bracket, Bottom Chain Attach 1
17 0902431 Bracket, Sequence Cable 4
18 0902445 Bracket, Sequence Cable 4
19 0961892 Bushing, Flanged 2
20 Cable, Sequence Options: 4
1060683 25EL
1060684 36EL
21 Cable, Extension Options: 4
1060685 25EL
1060655 36EL
22 Chain Assembly Options: 1
1260331 25EL
1260332 36EL
23 Chain Assembly Options: 2
1260333 25EL
1260334 36EL
24 Channel, Mast #1 Options: 1
1271389 25EL
1271394 36EL
25 Channel, Mast #2 Options: 1
1271390 25EL
1271395 36EL
26 Channel, Mast #3 Options: 1
1271391 25EL
1271396 36EL
