SECTION 3 MAST
S
E
C
T
I
O
N
3
M
A
S
T
38 3580217 Sheave, Cable 4
39 Sheave Assembly Options: 2
3580268 Prior to S/N 17519
3580286 S/N 17519 to Present
40 3580269 Sheave, Sequence Cable 3
41 3820006 Rivet (Prior to S/N 12269) 12
3820034 Rivet (S/N 12269 to Present) 12
42 3900187 Screw, Shoulder 3
43 3900190 Screw, Shoulder 1
44 3900192 Screw, Countersunk 3/8”-16NC x 1/2” 8
45 3900205 Screw, #10-24NC x 1/2”” 8
46 3900206 Bolt 1/4”-28NF x 3/8” 1
47 4060960 Shield, Mast Cover 2
48 4060961 Shield, Mast Cover 1
49 4070970 Shim, Cylinder Mount 2
50 4070971 Shim, Cylinder Mount 4
51 4160124 Spring 3
52 4567489 Tube, Spacer 2
53 4567492 Tube, Spacer 1
54 4567635 Tube, Spacer 2
55 4711400 Flatwasher 1/4” Narrow 53
56 4711500 Flatwasher 5/16” Narrow 3
57 4711800 Flatwasher 1/2” Narrow 4
58 Washer Options: 9
4712600 Flatwasher 1” Narrow (Prior to S/N 17519)
4740007 Thrust Washer (S/N 17519 to Present)
59 4740414 Cupwasher 6
60 4750800 Flatwasher #8 Wide 8
61 4751600 Flatwasher 3/8” Wide 12
62 4752600 Flatwasher 1” Wide 2
63 4761000 Lockwasher #10 8
64 4761400 Lockwasher 1/4” 3
65 4761500 Lockwasher 5/16” 1
66 Weld, Cylinder Mount Options: 1
4845731 (Prior to S/N 17519)
4846381 (S/N 17519 to S/N 19294)
4846514 (S/N 19294 to Present)
67 4845795 Weld, Cylinder Cable Mount 1
68 4070860 Shim, Slide Pad (.075) 14
69 4070861 Shim, Slide Pad (.036) 14
70 4070862 Shim, Slide Pad (.015) 10
71 Not Used
72 4070988 Shim, Slide Pad (.075) (S/N 15661 to Present) 2
73 4070989 Shim, Slide Pad (.036) (S/N 15661 to Present) 2
74 4070990 Shim, Slide Pad (.015) (S/N 15661 to Present) 2
— — — — — — — — — —
2901603 Mast Kit (Includes Items 23 - 27) 1
FIGURE 3-1. MAST ASSEMBLY - 20EL (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
