3120783 3-17
SECTION 3 MAST
S
E
C
T
I
O
N
3
M
A
S
T
.
FIGURE 3-4. MAST MOUNTED COMPONENTS INSTALLATIONS
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0258741 LOADING HARDWARE INSTALLATION 20EL/25EL/30EL Ref. F
1 0100011 Loctite #242 (Not Shown) A/R
2 0641409 Bolt 1/4”-20NC x 1 1/8” 4
3 0641608 Bolt 3/8”-16NC x 1” 4
4 0961892 Bushing, Flanged 2
5 2560088 Handle 2
6 2700092 Hook 1
7 2720130 Hose 2
8 3311605 Locknut 3/8”-16NC 4
9 3321701 Nut 7/16”-20NC 4
10 3340845 Pad, Slide Guide 2
11 3422744 Pin, Plunger 2
12 3450504 Pin, Cotter 8
13 3520163 End Cap, Tube 1
14 3820032 Rivet 2
15 3900190 Screw, Shoulder 2
16 4070860 Shim (.075) 2
17 4070861 Shim (.036) 2
18 4070862 Shim (.015) 2
19 4711600 Washer 3/8” 9
20 4711700 Washer 7/16” 8
21 4712200 Washer 3/4” 10
22 4751400 Washer 1/4” - Wide 4
23 4845706 Weldment, T-Bar 1
24 4845727 Bracket, Mast Wheel 2
25 4845868 Weldment 1
26 4845869 Weldment 1
27 4860186 Wheel 5” 2
28 Wheel 4” Options: A/R
4860185 Wheel (Prior to S/N 14095) 2
7020087 Wheel, Replacement (1 Per Wheel) 2
7020084 Bearing (2 Per Wheel) 4
7012631 Bushing, Axle Spanner (1 Per Wheel) 2
4860196 Wheel (S/N 14095 to Present) 2 A
Not Available Wheel, Replacement (1 Per Wheel) 2
7020084 Bearing (2 Per Wheel) 4
Not Available Bushing, Axle Spanner (1 Per Wheel) 2
29 AN960-T16L-1 Washer, Shim 4
30 AN960-T16L-2 Washer, Shim 6
31 Cap, Roller Options: 4
APL-P117 Prior to S/N 14776
AM-P2117 S/N 14776 to Present
32 BB6-CF-1-S Cam Follower 4
