Page 44
2-28
3120783
SECTION 2 CONTROLS
S
E
C
T
I
O
N
2
C
O
N
T
R
O
L
S
0258482
AUXILIARY LOWERING INSTALLATION
Ref.
A
201
Not Used
202
4360274
Switch, Push Button
1
203 to 204
Not Used
ACCESSORY OUTLET INSTALLATIONS
Ref.
0270748
(20EL) 120V (DC)
Ref.
B
0270749
(20EL) 240V (DC)
Ref.
B
0270975
(20EL) 120V (AC)
Ref.
B
0270976
(20EL) 240V (AC)
Ref.
B
0270773
(25EL) 120V (DC)
Ref.
B
0270774
(25EL) 240V (DC)
Ref.
B
0270978
(25EL) 120V (AC)
Ref.
B
0270979
(25EL) 240V (AC)
Ref.
B
0270776
(30EL) 120V (DC)
Ref.
B
0270777
(30EL) 240V (DC)
Ref.
B
0270981
(30EL) 120V (AC)
Ref.
B
0270982
(30EL) 240V (AC)
Ref.
B
0270779
(36EL) 120V (DC)
Ref.
B
0270780
(36EL) 240V (DC)
Ref.
B
0270984
(36EL) 120V (AC)
Ref.
B
0270985
(36EL) 240V (AC)
Ref.
B
0270782
(41EL) 120V (DC)
Ref.
B
0270783
(41EL) 240V (DC)
Ref.
B
0270987
(41EL) 120V (AC)
Ref.
B
0270988
(41EL) 240V (AC)
Ref.
B
301
0100011
Loctite #242 (Not Shown)
A/R
302
Bolt Options:
0641418
1/4” - 20NC x 2 1/4” (20EL/30EL/41EL)
1
Not Required
(25EL/36EL)
303
0721006
Bolt #10-24NC x 3/4”
2
304
0840946
Box, Receptacle
1
305
Cable, Electrical Options:
1060925
12/3 (20EL DC Only)
21.7ft/6.6m
4923069
20EL - AC (S/N 22888 to Present)
Ref.
A
4923071
25EL - DC (S/N 22888 to Present)
Ref.
A
4923073
25EL - AC (S/N 22888 to Present)
Ref.
A
4923077
30EL - DC (S/N 22916 to Present)
Ref.
A
4923079
30EL - AC (S/N 22916 to Present)
Ref.
A
4923083
36EL - DC (S/N 22916 to Present)
Ref.
A
4923085
36EL - AC (S/N 22916 to Present)
Ref.
A
4923089
41EL - DC (S/N 22916 to Present)
Ref.
A
4923091
41EL - DC (S/N 22916 to Present)
Ref.
A
1060564
12/3 Electrical Cable
A/R
4460018
Butt Splice, Terminal (20EL - DC/25EL - AC/36EL -
DC/36EL - AC)
3
4460315
Terminal, Fork (20EL - AC/25EL - AC/30EL - DC/
30EL - AC/36EL - AC/41EL - DC/41EL - AC)
A/R
FIGURE 2-8. CABLES AND CONTROLS INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
