1-4 3120783
SECTION 1 BASE
S
E
C
T
I
O
N
1
B
A
S
E
36 4740434 Washer, Nylon #8 24
37 4750800 Flatwasher #8 (Prior to S/N 19233) 12
38 4751000 Flatwasher #10 8
39 Base Weldment Options: 1
4845705 Prior to S/N 17519
4846388 S/N 17519 to Present
40 Wheel Assembly - Stationary Options: A/R
4860183 Stationary Wheel Used Prior to S/N 20788 2
7020083 Wheel, Replacement (1 Per Wheel) 2
7020084 Bearing (2 Per Wheel) 4
7012631 Bushing, Axle Spanner (1 Per Wheel) 2
4860246 Stationary Wheel Used S/N 20788 to Present
(No Service Parts Available) 2
41 Not Used
42 Wheel Assembly - 4” Options: A/R
4860185 4” Wheel Used Prior to S/N 20788 2
7020087 Wheel, Replacement (1 Per Wheel) 2
7020084 Bearing (2 Per Wheel) 4
7012631 Bushing, Axle Spanner (1 Per Wheel) 2
4860247 4” Wheel Used S/N 20788 to Present
(No Service Parts Available) 2
43 3571150 Plate, Wheel Spacer (S/N 12331 to Present) 1
44 3020017 Lubricant (Used Prior to S/N 20788) A/R
45 4240032 Tie, Wire (Not Shown) (S/N 16285 to Present) 18
46 2820086 Loom, Wire (Not Shown) (S/N 16285 to Present) 5.84ft/
1.8m
47 Use 4922752 Harness, Potted Relay (Not Shown) (Was P/N 4922421)
(Prior to S/N 19239) 1
OUTRIGGER ASSEMBLIES Ref.
0258466 20EL/25EL Ref. E
0258467 30EL Ref. E
0258468 36EL/41EL Ref. E
101 0100011 Loctite #242 (Not Shown) A/R
102 3300380 Locknut 1
103 0641410 Bolt 1/4”-20NC x 1 1/4” 1
104 0641624 3/8”-16NC x 3” (Prior to S/N 12074) 1
0641622 3/8”-16NC x 2 3/4” (S/N 12074 to Present) 1
105 1220015 Cap, End 1
106 Use 0962288 Bushing, Molded Nylon Insulator (S/N 16557 to Present)
(Prior to S/N 16557 - Was 2540024 (Grommet)) 2
107 2560127 Handle 1
108 2840019 Screw, Jack 1
109 3020035 Lubricant, Silicone A/R
110 3300392 Locknut Brass #8-32NC 2
111 3311405 Locknut 1/4”-20NC 1
112 3311605 Locknut 3/8”-16NC 1
113 3340712 Pad, Jack 1
FIGURE 1-1. BASE MOUNTED COMPONENTS INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
