3120783 2-19
SECTION 2 CONTROLS
S
E
C
T
I
O
N
2
C
O
N
T
R
O
L
S
.
FIGURE 2-6. BATTERY CHARGER ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0400176 BATTERY CHARGER ASSEMBLY Ref. F
1 to 4 Not Used
5 7011509 Breaker, Circuit - DC 50Amp 1
6 7018536 Breaker, Circuit 3 Amp 2
7 7020626 Card, Circuit 1
8 7020627 AC Cord Assembly 1
9 Not Used
10 7020629 DC Harness 1
11 Not Used
12 7020631 Rectifier Assembly 2
13 7018555 SCR Rectifier 1
14 7020605 Shunt Assembly 1
15 7018556 Connector, Strain Relief - DC 1
16 7011528 Connector, Strain Relief - AC 1
17 7018586 Switch, Slide 1
18 Not Used
19 7020032 Transformer 1
20 Not Used
21 7020633 Varistor 1
