3120783 2-13
SECTION 2 CONTROLS
S
E
C
T
I
O
N
2
C
O
N
T
R
O
L
S
.
FIGURE 2-4. DC POWER COMPONENTS INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
POWER PACK ASSEMBLY OPTIONS: Ref.
0258438 Prior to S/N 17519 Ref. A
0271130 S/N 17519 to Present Ref. D
1 0100011 Loctite, #242 (Not Shown) A/R
2 0630486 Screw, Countersunk 4
3 0641403 Bolt 1/4”-20NC x 3/8” 3
4 Bolt Options: 2
0641608 3/8”-16NC x 1” (Prior to S/N 17519)
0641606 3/8”-16NC x 3/4” (S/N 17519 to Present)
5 0721006 Screw 2
6 0721014 Screw (Prior to S/N 17519) 1
7 Ground Control Box Assembly Options: 1
0861212 Prior to S/N 20143
0861305 S/N 20143 to Present
7020078 Switch, Push-Pull (Stop) 1
7020096 Legend Plate, “Stop” 1
7020097 Legend Plate, “Power/Off/On” 1
Switch, Key Options: 1
7020098 Prior to S/N 20143
4360467 S/N 20143 to Present
Key, Replacement Options: 1
7016339 Prior to S/N 20143
2860030 S/N 20143 to Present
7020090 Connector, Strain Relief 1
7020093 Screw m3 x 25 4
7020094 Lid 1
8 0902054 Plate, Mounting 1
9 1060518 Cable, Battery (Prior to S/N 17519 Only) 1
10 1060571 Cable Assembly - Battery 1
11 3311005 Locknut #10-24NC A/R
12 3311505 Locknut 5/16”-18NC 4
13 DC Motor/Pump Assembly Options:
(See Figure 2-7 for Breakdown) 1
3600273 Prior to S/N 17519
3600320 S/N 17519 to Present
14 3740013 Solenoid (Prior to S/N 17519) 1
15 Relay Options: A/R
3740080 Relay, Bosch (Prior to S/N 17519)
3740049 (Skirted type) S/N 17519 to Present
16 3740113 Relay, Timer (Prior to S/N 17519) 1
17 4567605 Tube, Butyrate (Not Shown) (Prior to S/N 17519) 2
18 Washer 1/4” Options:
4711400 Prior to S/N 17519 3
4751400 S/N 17519 to Present 1
19 4751000 Washer #10 A/R
20 4751500 Washer 5/16” 4
21 4751600 Washer 3/8” 2
22 4845714 Bracket, Pump Mounting 1
