JLG 41EL Parts Manual User Manual
Page 19

3120783
2-3
SECTION 2 CONTROLS
S
E
C
T
I
O
N
2
C
O
N
T
R
O
L
S
.
FIGURE 2-1. AC POWER COMPONENTS INSTALLATION
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
POWERPACK ASSEMBLY OPTIONS:
Ref.
0258434
120 VOLT (Prior to S/N 17519)
Ref.
C
0271131
120 VOLT (S/N 17519 to Present)
Ref.
B
1
0630486
Screw, Counter Sunk
4
2
0641406
Bolt 1/4”-20NC x 3/4”
4
3
0721006
Screw
2
4
0721014
Screw (Prior to S/N 12076)
1
5
0860933
Junction Box Assembly (See Figure 2-2 for Breakdown)
1
6
Ground Control Box Assembly Options:
1
0861212
Prior to S/N 20143
0861305
S/N 20143 to Present
7020078
Switch, Push-Pull (Stop)
1
7020096
Legend Plate, “Stop”
1
7020097
Legend Plate, “Power/Off/On”
1
Switch, Key Options:
1
7020098
Prior to S/N 20143
4360467
S/N 20143 to Present
Key, Replacement Options:
1
7016339
Prior to S/N 20143
2860030
S/N 20143 to Present
7020090
Connector, Strain Relief
1
7020093
Screw m3 x 25
4
7020094
Lid
1
7
3311005
Locknut #10-24NC
A/R
8
3311405
Locknut 1/4”-20NC
4
9
3311505
Locknut 5/16”-18NC
4
10
Pump/Motor Assembly Options (See Figure 2-3 for
Breakdown):
1
3600281
Prior to S/N 12829
3600292
S/N 12829 to S/N 17519
3600322
S/N 17519 to Present
11
3740113
Relay, Timer (Prior to S/N 12076 Only)
1
12
4460566
Terminal, 90 Degrees
1
13
4751000
Flatwasher #10
A/R
14
4751400
Flatwasher 1/4”
8
15
4751500
Flatwasher 5/16”
4
16
4845712
Plate, Mounting
1
POWERPACK INSTALLATION OPTIONS:
Ref.
0258683
20EL (Prior to S/N 17519)
Ref.
C
0271139
20EL (S/N 17519 to Present)
Ref.
E
0258478
25EL/30EL/36EL/41EL (Prior to S/N 17519)
Ref.
B
0271137
25EL/30EL/36EL/41EL (S/N 17519 to Present)
Ref.
D
101
Not Used
102
0641404
Bolt 1/4”-20NC x 1/2”
4
103
Bolt Options:
4
0641610
Bolt 3/8”-16NC x 1 1/4” (20EL)
