3120783 2-9
SECTION 2 CONTROLS
S
E
C
T
I
O
N
2
C
O
N
T
R
O
L
S
.
FIGURE 2-3. AC MOTOR/PUMP ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
MOTOR/PUMP ASSEMBLY OPTIONS: Ref.
3600281 Prior to S/N 12829 Ref. A
3600292 S/N 12829 to 17519 Ref. C
3600322 S/N 17519 to Present Ref. C
1 Bolt Options: 2
7013713 5/16”-24NF x 2 3/4” (Prior to S/N 17519)
3600281/3600292 Assemblies
7022222 5/16”-24NF x 2 1/2” (S/N 17519 to Present)
3600322 Assemblies
2 7016735 Coupling 1
3 7013714 Plug 1
4 7013715 Ball 1
5 7013716 Seal 1
6 Washer Options: 1
7013717 3600281/3600292 Assemblies (Prior to S/N 17519)
7022217 3600322 Assemblies (S/N 17519 to Present)
7 Not Used
8 7013722 Magnet 1
9 7016713 Decal - Fill Line 1
10 Screw Options: 2
7013728 3600281/3600292 Assemblies (Prior to S/N 17519)
Not Required 3600322 (S/N 17519 to Present)
11 Cover Options: 1
7016770 3600281/3600292 Assemblies (Prior to S/N 17519)
Not Required 3600322 (S/N 17519 to Present)
12 Gasket Options: A/R
7016764 3600281 Assemblies (Prior to S/N 12829) 1
7016793 3600292 Assemblies (S/N 12829 to 17519) 1
Not Required 3600322 Assemblies (S/N 17519 to Present)
13 Not Used
14 7016771 Clamp 1
15 7016774 Motor 1
16 Cover, Switch Box Options: A/R
7013787 3600281 Assemblies (Prior to S/N 12829) 1
7016787 3600292 Assemblies (S/N 12829 to 17519) 1
7016787 3600322 Assemblies (S/N 17519 to Present)
17 7013708 Cartridge, Valve - Check 1
18 7016720 Bolt 5/16”-18NC x 1” (Prior to S/N 17519) 1
19 7016757 Bolt M6-1.0 35MM 4
20 7016758 Lockwasher 1/4” 4
21 7016721 Bolt #12-24NC x 1/2” 4
22 7013795 Tube, Return 1
23 7016773 Plumbing Assembly - Inlet 1
24 Not Used
25 Not Used
26 Not Used
