JLG 2658E3 ANSI Parts Manual User Manual
Page 97

3120763
4-19
SECTION 4
PLATFORM
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
PLATFORM ACCESS (STANDARD GATE)
INSTALLATIONS
Ref.
0259385
Standard Gate - 1532E3/1932E3
Ref.
2
0258229
Standard Gate - 2033E3
Ref.
4
0258234
Standard Gate - 2046E3
Ref.
5
1
Tube, Rail Options:
1
4565201
1532E3/1932E3/2033E3
4565202
2046E3
2
3340612
Pad
1.5ft/.5m
3
Nut Options:
A/R
3300151
Nut, Acorn 1/4”-20NC (Prior to S/N 0200098334)
2080063
Fastener, Nut 1/4”-20NC
(S/N 0200098334 to Present)
4
4751400
Flatwasher 1/4” Wide
12
5
0100011
Loctite #242 (Prior to S/N 0200098334)
A/R
6
3520072
Plug, Cap
2
7
3911428
Screw 1/4”-20NC x 1 3/4”
A/R
8
Screw Options:
4
3911444
Screw 1/4”-20NC x 2 3/4”
(Prior to S/N 0200098334)
2080065
Fastener, Screw 1/4”-20NC x 2 3/4”
(S/N 0200098334 to Present)
9
0641608
Bolt 3/8”-16NC x 1”
A/R
10
3311605
Locknut 3/8”-16NC
A/R
11
4751600
Flatwasher 3/8”
A/R
12
Weldment, End Rail
A/R
Not Required
1532E3/1932E3/2033E3
0
4845760
2046E3
1
13
Kick Plate - Rear
A/R
Not Required
1532E3/1932E3/2033E3
0
3534742
2046E3
1
14
1260136
Chain
2ft/.6m
15
3010088
Link
2
16
Use 1001101076
Hook, Snap (Includes Item 15) (was p/n
2940064)
1
17
2820097
Mesh Tubing
2ft/.6m
18
0641418
Bolt 1/4”-20NC x 2 1/4”
A/R
— — — — — — — —
2902000
Kit, Platform Access - 2046E3
(Includes Items 12 & 13)
1
