JLG 2658E3 ANSI Parts Manual User Manual
Page 121
3120763
4-43
SECTION 4
PLATFORM
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
FIGURE 4-8. PLATFORM AND EXTENSION INSTALLATION - POWER OPERATED (2033E3/2046E3/
2646E3/2658E3)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
POWER DECK EXTENSION ASSENBLIES
Ref.
3510643
2033E3 (WITH 4 FT. Power Deck Extension)
Ref
5
3510642
2033E3 (WITH 6 FT. Power Deck Extension)
Ref
6
3510645
2046E3/2646E3 (WITH 4 FT. Power Deck Extension)
Ref
6
3510644
2046E3/2646E3 (WITH 6 FT. Power Deck Extension)
Ref
6
3510647
2658E3 (WITH 4 FT. Power Deck Extension)
Ref
7
3510646
2658E3 (WITH 6 FT. Power Deck Extension)
Ref
6
1
Power Deck Extension Weldment Options:
1
3510702
2033E3
3510703
2046E3/2646E3
3510704
2658E3
2
Shield, Front Options:
1
4060929
2033E3
4060930
2046E3/2646E3
4060931
2658E3
3
Plate, Power Extension Deck Options:
1
3570003
2033E3
3570004
2046E3/2646E3
3570005
2658E3
4
4845416
Weldment, Extension Tube (Right Side)
1
5
4845415
Weldment, Extension Tube (Left Side)
1
6
3340812
Pad (Rear Top)
2
7
0641404
Bolt 1/4”-20NC x 1/2”
4
8
3340813
Pad (Rear Bottom)
2
9
3311405
Locknut 1/4”-20NC
4
10
4751400
Flatwasher 1/4”
6
11
0741407
Screw, Flathead 1/4”-20NC x 7/8”
2
12
3340850
Pad
2
13
3911408
Screw, Round Head 1/4”-20NC x 1/2”
4
14
0100011
Loctite #242
A/R
15
0641608
Bolt 3/8”-16NC x 1”
8
16
4751600
Flatwasher 3/8”
16
17
3311605
Locknut 3/8”
12
18
3340825
Pad (Front)
2
19
0641604
Bolt 3/8”-16NC x 1/2”
4
20
4761600
Lockwasher 3/8”
2
21
Bracket, Switch Mount Options:
1
0902512
2033E3/2046E3/2646E3
0902512
2658E3 (Prior to S/N 0200073911)
0902665
2658E3 (S/N 0200073911 to Present)
22
4360401
Switch, Extension Limit
1
23
3931024
Bolt #10-24NC x 1 1/2”
2
24
4751000
Flatwasher #10
2
25
3311005
Locknut #10-24NC
2
26
1320026
Clamp 1 3/4”
2
