Page 33

3120763
1-27
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
703
0641610
Bolt 3/8”-16NC x 1 1/4”
8
704
3311605
Locknut 3/8”-16NC
8
705
4711600
Flatwasher 3/8”
8
0257372
STATIC STRAP INSTALLATION (OPTIONAL)
Ref.
4
801
Strap, Static Options:
1
Use 4240147
(Prior to S/N 0200103629) (was p/n 4240084)
4240147
(S/N 0200103629 to Present)
802
3941406
Self Tapping
1
803
Not Used
804
4751400
Flatwasher 1/4”
1
0257266
TIE-DOWN INSTALLATION
Ref.
3
901
3760365
D-Ring
2
902
0630485
Bolt, Carriage 3/8”-16NC x 1”
4
903
4751600
Flatwasher 3/8” (Prior to S/N 0200065687)
4
904
3311605
Locknut 3/8”-16NC
4
FIGURE 1-7. FRAME MOUNTED COMPONENTS INSTALLATIONS (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
