JLG 2658E3 ANSI Parts Manual User Manual
Page 69

3120763
3-11
SECTION 3 SCISSOR ARMS
S
E
C
T
I
O
N
3
S
C
I
S
S
O
R
A
R
M
S
.
FIGURE 3-3. SCISSOR ARMS INSTALLATION - 2033E3
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
SCISSOR ARMS INSTALLATION - 2033E3
Ref.
0258083
Standard Machines without Power Deck
Ref.
8
0259369
Standard Machines with Power Deck
Ref.
5
0258778
1000# Capacity Machines
Ref.
8
1
Not Used
2
Arm Weldment (Lower Inboard) Options:
1
0200565
Standard Machines
0200624
1000# Capacity Machines
3
0200566
Arm Weldment (Mid Inboard)
1
4
Arm Weldment (Upper Inboard) Options:
1
0200567
Machines without Power Deck
0200670
Machines with Power Deck
5
Arm Weldment (Bottom Outboard) Options:
1
0200568
Standard Machines
0200623
1000# Capacity Machines
6
0200569
Arm Weldment (Mid Outboard)
2
7
0200570
Arm Weldment (Top Outboard)
1
8
3422711
Pin
14
9
3422712
Pin
2
10
3422714
Pin
2
11
3422713
Pin
2
12
Not Used
13
3422709
Pin
2
14
3340629
Pad, Slide Block
2
15
4740438
Washer, Special
18
16
3760387
Ring, Retaining
18
17
0641522
Bolt 5/16”-18NC x 2 3/4”
2
18
0630523
Bolt
8
19
3321801
Nut
8
20
3311505
Locknut 5/16”-18NC
4
21
3340841
Pad,
3
22
1683627
Lift Cylinder Assembly (See Section 5 for Breakdown)
1
23 to 32
Not Used
33
0962220
Bushing, Garmax
32
34
Not Used
35
0641508
Bolt 5/16”-18NC x 1”
2
36
0641620
Bolt 3/8”-16NC x 2 1/2”
8
37
4240128
Strap
1
38
4846024
Weldment, Safety Prop
1
39
4240125
Strap
2
40
0641638
Bolt 3/8”-16NC x 4 3/4”
8
41
3311605
Locknut 3/8”-16NC
16
42
4711600
Flatwasher 3/8” Narrow
18
43
4845560
Weldment, Stationary Pivot (Top)
2
44
4845559
Weldment, Stationary Pivot (Bottom)
2
45
Not Used
46
4711800
Flatwasher
8
