Page 113
3120763
4-35
SECTION 4
PLATFORM
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
FIGURE 4-7. PLATFORM ACCESS INSTALLATION - FOLDDOWN HANDRAILS (MANUALLY
OPERATED EXTENSION)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
PLATFORM ACCESS (STANDARD GATE)
INSTALLATIONS
Ref.
0259386
Standard Gate with Chain Gate - 1532E3/1932E3
Ref.
2
0258229
Standard Gate with Chain Gate - 2033E3
Ref.
4
0258238
Standard Gate with Chain Gate- 2046E3/2646E3
Ref.
6
0258243
Standard Gate with Chain Gate - 2658E3
Ref.
6
1
Tube, Rail Options:
1
4565285
1532E3/1932E3
4565201
2033E3
4565202
2046E3/2646E3
4565203
2658E3
2
3340612
Pad
1.5ft/.5m
3
Nut Options:
A/R
3300151
Nut, Acorn 1/4”-20NC (Prior to S/N 0200098334)
2080063
Fastener, Nut 1/4”-20NC (S/N 0200098334 to
Present)
4
4751400
Flatwasher 1/4” Wide
A/R
5
0100011
Loctite #242 (Prior to S/N 0200098334)
A/R
6
3520072
Plug, Cap
A/R
7
0641418
Screw 1/4”-20NC x 2 1/4”
A/R
8
3911428
Bolt 1/4”-20NC x 1 3/4”
A/R
9
Screw Options:
A/R
3911444
Screw 1/4”-20NC x 2 3/4” (Prior to S/N
0200098334)
2080065
Fastener, Screw 1/4”-20NC x 2 3/4” (S/N
0200098334 to Present)
10
0641608
Bolt 3/8”-16NC x 1”
A/R
11
3311605
Locknut 3/8”-16NC
A/R
12
4751600
Flatwasher 3/8”
A/R
13 to 18
Not Used
19
Weldment, Rear Vertical Options:
A/R
Not Required
1532E3/1932E3/2033E3
0
4845741
2046E3/2646E3/2658E3
1
20
Weldment, Bottom Right Side Options:
A/R
Not Required
1532E3/1932E3/2033E3
0
4845843
2046E3/2646E3
1
4845734
2658E3
1
21
Weldment, Bottom Left Side Options:
A/R
Not Required
1532E3/1932E3/2033E3
0
4845845
2046E3/2646E3
1
4845736
2658E3
1
22
Kick Plate - Rear Options:
A/R
Not Required
1532E3/1932E3/2033E3
0
3534742
2046E3/2646E3
2
3534743
2658E3
2
23
Not Used
