Page 55

3120763
2-19
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
FIGURE 2-5. BATTERY INSTALLATIONS
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
BATTERY INSTALLATIONS - 1532E3/1932E3
Ref.
0258960
Standard Machines
Ref.
4
0258961
UL Machines
Ref.
5
1
1780290
Battery Door Weldment
1
2
0181880
Angle, Mounting
2
3
Battery Options:
4
Use 0400215
(Prior to S/N 0200112192)(was p/n 0400169)
0400215
(S/N 0200112192 to Present)
4
0641408
Bolt 1/4”-20NC x 1”
2
5
4751400
Flatwasher 1/4” (Prior to S/N 0200111444)
11
6
3311401
Nut 1/4”-20NC (Prior to S/N 0200111444)
4
7
0100011
Loctite #242
A/R
8
0362566
Bar, Hinge
2
9
0962004
Bushing, Flanged Bronze
2
10
0641816
Bolt 1/2”-13NC x 2”
4
11
4751800
Flatwasher 1/2”
8
12
3311801
Nut 1/2”-13NC
4
13
3960389
Seal
34”/86.4cm
14
0641406
1/4”-20NC x 3/4”
7
15
2940098
Latch
1
16
2560137
Knob
1
17
1060711
Cable - 12in/30.5cm (Prior to S/N 0200081384)
1
18
0840031
Boot (Right Hand)
8
19
Cable - 9in/23cm Options:
3
Use 1061017
(Prior to S/N 0200112192) (Was P/N 1060665)
1061017
(S/N 0200112192 to Present)
20
Not Used
21
4711400
Flatwasher 1/4” - Narrow
12
22
2820088
Phenolic 10 x 20 x 1/16 (Not Shown - UL Machines Only)
4
23
2820084
Phenolic 10 x 8 x 1/16 (Not Shown - UL Machines Only)
2
24
4240084
Static Strap (Not Shown - UL Machines Only)
1
25
4761400
Lockwasher 1/4”
1
26
0902365
Bracket, Latch Mounting
1
27
3311405
Locknut 1/4”-20NC
6
28
Hardware Options (Not Shown - UL Machines Only):
4
3941404
Self-Tapping 1/4” x 1/2” (Prior to S/N 0200097289)
3820020
Pop Rivet (S/N 0200097289 to Present)
29
Flatwasher Options (Not Shown - UL Machines Only):
4
4751400
Flatwasher 1/4” (Prior to S/N 0200097289)
4751000
Flatwasher #10 (S/N 0200097289 to Present)
30
3300429
Nut 5/16”-18NC Stainless (Prior to S/N 0200112192)
8
31
4740474
Lockwasher 5/16” Stainless (Prior to S/N 0200112192)
8
32
0630526
Bolt 5/16”-18NC x 1 1/4” Stainless
(Prior to S/N 0200112192)
8
33
0100051
Grease, Battery
A/R
