SECTION 1 FRAME
102 Spindle Options:
4130332 Standard 2
4130349
Japanese Spec 2
103 0641826 Bolt 1/2”-13NC x 3 1/4” 8
104 4740453 Flatwasher 1/2” 10
105 3311801 Nut 1/2”-13NC 8
106
Use 0100019
Loctite (Prior to S/N 02000103431) (Was P/N 0100011) A/R
107 3450406 Cotter Pin 1/8” x 1 1/2” 2
108 3300255 Nut, Wheel 10
109
2780216
Hub 2
109A
7012613
Bolt, Wheel (5 Per Hub) 10
110 Steer Cylinder Options: 1
Use 1684227 Prior to S/N 0200070496 (was p/n 1683429)
Use 1684227
S/N 0200070496 to S/N 0200078796 (was p/n
1683840)
Use 1684227
S/N 0200078796 to S/N 0200105071 (was p/n
1683937)
1684227 S/N 0200105071 to Present
111 Tie Rod Options:
3841320
2046E3/2646E3 1
3841324
2658E3 1
112 2160008 Grease Fitting (Prior to S/N 0200088491 Only) 2
113 3430812 Clevis Pin 1/2” x 1 1/2” 1
114
3450403
Cotter Pin 1/8” x 3/4” 2
115 0630495 Bolt, Shoulder 3/4” x 1” 2
116 0962014 Bushing 2
117
0962013
Bushing, Fiberglide 2
118
3430824
Clevis Pin 1/2” x 3” 1
119 3780166 O-Ring 2
120 4740419 Washer, Thrust 2
121
1120417
Cap 2
122 Bolt Options: 2
0641611 3/8”-16NC x 1 3/8” (1532E3/1932E3 Only)
0641612 3/8”-16NC x 1 1/2” (2033E3 Only)
123
4711600
Flatwasher 3/8” 2
124
4566833
Spacer 2
125 Not Required
126 4761800 Lockwasher 1/2” (Prior to S/N 0200088491Only)
127
0962017
Bushing, Excelite 4
128 Cover, Motor (2646E3 Japanese Spec Only) 2
Use 1670910 Prior to S/N 66042 (Was p/n 1670839)
129 0641412 Bolt 1/4”-20NC x 1 1/2” (2646E3 Japanese Spec Only) 8
130
4711400
Washer 1/4” (2646E3 Japanese Spec Only) 16
131 0100081 Loctite #454 A/R
132 1120064 Cap, Grease Fitting, (Prior to S/N 0200088491 Only) 2
FIGURE 1-1. DRIVE AND STEERING INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
