JLG 2658E3 ANSI Parts Manual User Manual
Page 56

2-20
3120763
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
BATTERY INSTALLATIONS -
2033E3/2046E3/2646E3/2658E3
Ref.
0258611
Standard Machines
Ref.
7
0258619
Hi Output Machines
Ref.
8
0258106
UL Machines - 2033E3/2046E3/2646E3
Ref.
8
0258107
UL Machines - 2658E3
Ref.
8
0258625
UL Hi Output - 2033E3/2046E3/2646E3
Ref.
8
0258624
UL Hi Output - 2658E3
Ref.
8
101
4845802
Battery Door Weldment
1
102
Battery Options:
0400169
Battery - Standard
4
Battery - UL Options:
4
Use 0400215
(Prior to S/N 0200112192) (was p/n 0400169)
0400215
(S/N 0200112192 to Present)
Battery - Hi Output Options:
4
Use 0400216
(Prior to S/N 0200112192) (was p/n 0400151)
0400216
(S/N 0200112192 to Present)
103
4845873
Hinge
2
104
0181622
Angle, Battery Hold-down
1
105
0791608
Bolt 3/8”-16NC x 1”
8
106
Not Used
107
3311608
Locknut, Flanged 3/8”-16NC
8
108
Not Used
109
4845130
Hinge
2
110
0962004
Bushing, Flanged Bronze
8
111
3538844
Plate
2
112
0641412
Bolt 1/4”-20 x 1 1/2”
2
113
1060710
Cable, Battery
1
113A
1060243
Cable
9ft/2.74m
113B
4460778
Connector, Anderson
2
113C
4460443
Terminal Eyelet
4
114
Cable, Battery Options:
3
Use 1061017
(Prior to S/N 0200112192) (was p/n 1060665)
1061017
(S/N 0200112192 to Present)
115
0840031
Boot, Terminal
8
116
2820084
Phenolic 10 x 10 x 1/16 (Not Shown - UL Machines Only)
10
117
2820098
Phenolic 6 x 30 x 1/16 (Not Shown - UL Machines Only)
(2658E3)
1
2820087
Phenolic 10 x 30 x 1/16 (Not Shown - UL Machines Only)
(2033E3/2046E3/2646E3)
1
118
2940100
Latch, Folding T-Handle (Left Side)
1
119
2940101
Latch, Folding T-Handle (Right Side)
1
120
4220166
Stop, Door
1
121
0641424
Bolt 1/4”-20NC x 1”
1
122
3311405
Locknut 1/4”-20NC
4
123
4711400
Flatwasher 1/4” Narrow
14
124
0641408
Bolt 1/4”-20NC x 1”
3
125
3311001
Nut #10-24NC (Standard Machines Only)
8
FIGURE 2-5. BATTERY INSTALLATIONS (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
