Page 119
3120763
4-41
SECTION 4
PLATFORM
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
326
Fastener, Rivnut #10-32 Options:
12
Use 2080069
(Prior to S/N 0200103629) (was p/n 2080047)
2080069
(S/N 0200103629 to Present)
327
3900267
Screw #10-32
12
328
4711000
Flatwasher #10
12
329
2600253
Hinge
2
330
4845710
Weldment, Platform Access Rail
1
331
2940074
Latch
1
332
3911016
Bolt #10-24NC x 1”
4
333
Nut Options:
4
3311005
Locknut #10-24NC (Prior to S/N 0200099828)
3311001
Nut #10-24NC (S/N 0200099828 to Present)
334
4751000
Flatwasher #10
4
335
3422369
Pin, Plunger (S/N 0200057691 to Present)
2
336
0641418
Bolt 1/4”-20NC x 2 1/4”
A/R
— — — — — — — —
2901993
Kit, Platform Access Rails - 1532E3/1932E3/2033E3/
2046E3/2646E3/2658E3 (Includes Items 319,321 &
330)
1
2902011
Kit, Platform Access Rails - 2046E3/2646E3
(Includes Items 315,316,317,318, & 320)
1
2902012
Kit, Platform Access Rails - 2658E3 (Includes Items
315,316,317,318, & 320)
1
FIGURE 4-7. PLATFORM ACCESS INSTALLATION - FOLDDOWN HANDRAILS (MANUALLY
OPERATED EXTENSION) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
